Perma FLEX M125 Lubricant dispenser with low viscosity bio oil SO64

Perma Flex M125 Lubricant dispenser with oil SO64 | N° 107202

Perma Bio oil, low viscosity SO64

• Multi-purpose oil
• Rapidly biodegradable
• Water hazard class 1
• Meet CLP requirements
• Excellent viscosity-temperature relation
• Good antiwear behavior
• Very adhesive
• FZG test A/8.3/90 scuffing load stage ≥ 12

Technical specifications

• Base oil: ester
• ISO VG DIN 51519: 100
• Cinematic oil viscosity, DIN 51561,
  • at 40 °C, mm²/s: 100
  • at 100 °C, mm²/s: 15
• Colour: orange
• Density, DIN 51757, at 20 °C, g/cm3 approx.: 0.94
• Viscosity index, DIN ISO 2909: > 140
• Pourpoint, DIN ISO 3016, °C: < -30
• Service temperature range, °C: – 30 to 110

Applications

• perma Bio oil, low viscosity SO64 is used for the lubrication of open drive and con-veyor chains, spindles and joints as well as for spur, bevel and worm gears and pertinent machine elements, such as couplings, plain and rolling bearings.
• perma Bio oil, low viscosity SO64 is used in agricultural and forestry equipment, water treatment installations, gardening equipment.
• perma Bio oil, low viscosity SO64 is especially suitable for applications where oil leakage might contaminate the environment.

Perma Flex M125 Lubricant dispenser

• The automatic lubrication system perma FLEX is available in two convenient sizes (60 cm³ / 125 cm³).
• It can be used for inside or outside applications at temperatures ranging from -20 °C to +60 °C.
• Discharge period setting is flexible and can be adjusted from 1 – 12 months using the dial on top of the lubricator.
• Perma FLEX comes fully assembled and ready-to-use. Simply turn the dial to the desired discharge period and the system is activated.
• The electronically controlled chemical reaction will build up the pressure that is necessary to continually supply the lubrication point with fresh lubricant.
