Perma CLASSIC 120 Single-point lubricator with high-perf grease SF04

Perma CLASSIC SF04 120 cm³ automatic single-point lubricator with high performance grease | N° 100052

Perma High performance grease SF04

• Multipurpose lubricant for extreme requirements
• Powerful at high temperatures & vibrations
• Resistant to aggressive media

Technical specifications

• Color: beige
• NLGI-grade:  0/1
• Thickener: Polyurea
• Base oil: Mineral oil + PAO
• Operating temperature: -20 to+160
• Viscosity at +40 °C [mm²/s]: 500
• Speed index: 200,000

Applications

• Roller bearings
• Sliding bearings
• Linear guides
• Open gears / gear racks
• Spindles

Hazards (CLP)

Signal word: Warning

Hazard Statements

• H319: Causes serious eye irritation.

Precautionary Statements (P-Sätze)

Prevention:

• P264: Wash skin thoroughly after handling.
• P280: Wear eye protection / face protection.

Response:

• P305 + P351 + P338: IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing.
• P337 + P313: If eye irritation persists: Get medical advice / attention.

Perma CLASSIC 120 Automatic lubrication system

• Perma CLASSIC is a single-point lubrication system for roller- and sliding bearings, sliding guides, open gears, gear racks, spindles, shaft seals, chains, etc.
• Operates at ambient temperatures between 0 up to +40 °C.
• Typical applications can be found in mining, steel, automotive and mechanical engineering.
• The reliable operating principle is based on an electrochemical reaction.
• The lubrication period is determined by color coded activator screws.
• Depending on your application’s requirement, you may choose to discharge 120 cm³ in a period of 1, 3, 6 or 12 months.
• The activator screw generates pressure (max. 4 bar) which moves the piston forward and continuously injects small lubricant amounts into the lubrication point
• Perma CLASSIC is fully dust and water proof and can withstand impacts and accidental knocks.

Note: For each Classic 120 dispenser you need an activator screw, which you can order under the links below:
