Perma CLASSIC 120 Single-point lubricator with high-temp grease SF05

Perma CLASSIC SF05 120 cm³ automatic single-point lubricator with high temperature grease | N° 100063

Perma High temp. / Extreme pressure grease SF05

• ​Multipurpose grease for extreme requirements
• High load-carrying capacity
• Good dry-running properties thanks to solid lubricants

Technical specifications

• Color: black
• NLGI-grade:  0/1
• Thickener: Polyurea + MoS2
• Base oil: Mineral oil + PAO
• Operating temperature: -20 to+160
• Viscosity at +40 °C [mm²/s]: 500
• Speed index: 200,000

Applications

• Roller bearings
• Sliding bearings
• Open gears / gear racks

Perma CLASSIC 120 Automatic lubrication system

• Perma CLASSIC is a single-point lubrication system for roller- and sliding bearings, sliding guides, open gears, gear racks, spindles, shaft seals, chains, etc.
• Operates at ambient temperatures between 0 up to +40 °C.
• Typical applications can be found in mining, steel, automotive and mechanical engineering.
• The reliable operating principle is based on an electrochemical reaction.
• The lubrication period is determined by color coded activator screws.
• Depending on your application’s requirement, you may choose to discharge 120 cm³ in a period of 1, 3, 6 or 12 months.
• The activator screw generates pressure (max. 4 bar) which moves the piston forward and continuously injects small lubricant amounts into the lubrication point
• Perma CLASSIC is fully dust and water proof and can withstand impacts and accidental knocks.

Note: For each Classic 120 dispenser you need an activator screw, which you can order under the links below:
