Perma CLASSIC 120 Single-point lubricator with Mobil XHP 222

Perma CLASSIC ​​Mobil XHP 222 120 cm³ automatic single-point lubricator with high temperature bearing grease | N° 100305

Mobilgrease XHP 222

Mobil Mobilgrease XHP 222 is a KP 2 N -20 lithium complex soap grease for excellent lubricity at low temperatures.

Application

• Mobilgrease XHP 222 is recommended by ExxonMobil for industrial and marine applications, chassis components and farm equipment. Its sticky formulation stays in applications longer.
• Wide range of applications including the industrial, automotive, construction and marine sectors

Specifications & Approvals

• DIN 51825:2004-06 – KP 2 N -20
• Fives Cincinnati P-64
• NLGI HPM+WR

Features

• Excellent lubricity at low temperatures (down to -20°C)
• Superb resistance to water washout and spray-off
• Highly adhesive and cohesive structure
• Excellent rust and corrosion resistance
• Very good resistance to thermal, oxidative and structural degradation at high temperature
• Very good anti-wear and EP performance
• Broad multi-purpose application
• Container size: 390g canister
• Also available in: 18kg bucket, 50kg and 180kg drum

Advantages and Potential Benefits

• Helps assure proper lubrication and protection even in the most severe water exposure conditions
• Excellent grease tenacity, helps reduce leakage and extend re-lubrication intervals for reduced maintenance requirements
• Protection of lubricated parts even in hostile aqueous environments
• Helps extend grease life and enhance bearing protection in high temperature applications helping to reduce maintenance and replacement costs
• Reliable protection of lubricated equipment, even under conditions of high sliding with potential for extended equipment life and reduced unanticipated downtime
• Provides potential for inventory rationalization and reduced inventory costs

Technical specifications

Perma CLASSIC 120 Automatic lubrication system

• Perma CLASSIC is a single-point lubrication system for roller- and sliding bearings, sliding guides, open gears, gear racks, spindles, shaft seals, chains, etc.
• Operates at ambient temperatures between 0 up to +40 °C.
• Typical applications can be found in mining, steel, automotive and mechanical engineering.
• The reliable operating principle is based on an electrochemical reaction.
• The lubrication period is determined by color coded activator screws.
• Depending on your application’s requirement, you may choose to discharge 120 cm³ in a period of 1, 3, 6 or 12 months.
• The activator screw generates pressure (max. 4 bar) which moves the piston forward and continuously injects small lubricant amounts into the lubrication point
• Perma CLASSIC is fully dust and water proof and can withstand impacts and accidental knocks.

Note: For each Classic 120 dispenser you need an activator screw, which you can order under the links below:
