Perma FLEX M125 Lubricant dispenser with special oil Structovis FHD

Perma Flex M125 Lubricant dispenser with special oil Structovis FHD | N° 117628

Klüber special oil Structovis FHD

• Good wear protection
• Good corrosion protection
• Adhesive
• Noise dampening (depending on viscosity)
• Emergency lubricating properties (BHD MF)

Technical specifications

• Lower service temperature: -10 °C
• Upper service temperature: 120
• Colour space: brown
• Density, DIN 51757, 20 °C: ca. 0,89 g/cm³
• Kinematic viscosity, DIN 51562 pt. 01/ASTM D445/ASTM D 7042, 40 °C: ca. 150 mm²/s

Applications

• STRUCTOVIS HD lubricants are used for driving, control and conveyor chains
• STRUCTOVIS BHD and BHD 75 S have proven particularly effective for the initial lubrication of steel link chains by the chain manufacturer

Perma Flex M125 Lubricant dispenser

• The automatic lubrication system perma FLEX is available in two convenient sizes (60 cm³ / 125 cm³).
• It can be used for inside or outside applications at temperatures ranging from -20 °C to +60 °C.
• Discharge period setting is flexible and can be adjusted from 1 – 12 months using the dial on top of the lubricator.
• Perma FLEX comes fully assembled and ready-to-use. Simply turn the dial to the desired discharge period and the system is activated.
• The electronically controlled chemical reaction will build up the pressure that is necessary to continually supply the lubrication point with fresh lubricant.

Information on product safety (Manufacturer, Contact)

perma-tec GmbH & Co. KG, Hammelburger Str. 21, 97717 Euerdorf, Deutschland, +49 9704 609-0, [email protected]
