Perma CLASSIC 120 Single-point lubricator with Microlube GB 0 grease

Perma CLASSIC 120 cm³ automatic single-point lubricator with MICROLUBE GB 0 grease | N° 100109

MICROLUBE GB 0 Universal high-performance lubricant

• Universal high-performance lubricant
• High pressure absorption capacity
• Good wear protection
• Good anticorrosion behaviour
• Pumpable through centralized systems

Technical specifications

• Texture: homogeneous
• Colour space: red
• Density at 20 °C: approx. 0.90 g/cm³
• Base oil viscosity at 40 °C, calculated value: approx.:590 mm²/s
• Base oil viscosity at 100 °C, calculated value: approx. 31.5 mm²/s
• Shear viscosity at 25 °C, shear rate 300 s-1; equipment:rotational viscometer: approx. 3 000 mPas
• Drop point, DIN ISO 2176, IP 396: > 180 °C

Applications

• MICROLUBE GB 0 was especially developed for friction points subject to high loads and mixed friction conditions.
• It is a universal grease suitable for the lubrication of eccentric presses (e.g. make Müller-Weingarten), heavy-duty spur and bevel gears with steel/steel components (e.g. gear motors that are not oiltight), slideways, guides and sump lubricated rolling bearings.

Hazard Information (CLP)

Signal word: Warning

Hazard statements (H-codes)

• H319: Causes serious eye irritation.

Precautionary statements (P-codes)

Prevention:

• P264: Wash skin thoroughly after handling.
• P280: Wear eye protection/face protection.

Response:

• P305 + P351 + P338: IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing.
• P337 + P313: If eye irritation persists: Get medical advice/attention.

Additional Labelling (EUH-codes)

• EUH208: Contains dibutyl[[bis[(2-ethylhexyl)oxy]phosphinothioyl]thio]succinate. May produce an allergic reaction.

Perma CLASSIC 120 Automatic lubrication system

• Perma CLASSIC is a single-point lubrication system for roller- and sliding bearings, sliding guides, open gears, gear racks, spindles, shaft seals, chains, etc.
• Operates at ambient temperatures between 0 up to +40 °C.
• Typical applications can be found in mining, steel, automotive and mechanical engineering.
• The reliable operating principle is based on an electrochemical reaction.
• The lubrication period is determined by color coded activator screws.
• Depending on your application’s requirement, you may choose to discharge 120 cm³ in a period of 1, 3, 6 or 12 months.
• The activator screw generates pressure (max. 4 bar) which moves the piston forward and continuously injects small lubricant amounts into the lubrication point
• Perma CLASSIC is fully dust and water proof and can withstand impacts and accidental knocks.

Note: For each Classic 120 dispenser you need an activator screw, which you can order under the links below:
