Perma CLASSIC 120 Single-point lubricator with grease SF02

Perma CLASSIC SF02 120 cm³ automatic single-point lubricator with extreme pressure grease | N° 100034

Perma Extreme pressure grease SF02

• High-pressure grease with MoS2
• Ageing- & oxidation-resistant
• Good dry-running properties

Technical specifications

• Color: grey
• NLGI-grade: 2
• Thickener: Li + MoS2
• Base oil: Mineral oil
• Operating temperature: -30 to +120
• Viscosity at +40 °C [mm²/s]: 100
• Speed index: 350,000

Applications

• Sliding bearings
• Open gears / gear racks

Perma CLASSIC 120 Automatic lubrication system

• Perma CLASSIC is a single-point lubrication system for roller- and sliding bearings, sliding guides, open gears, gear racks, spindles, shaft seals, chains, etc.
• Operates at ambient temperatures between 0 up to +40 °C.
• Typical applications can be found in mining, steel, automotive and mechanical engineering.
• The reliable operating principle is based on an electrochemical reaction.
• The lubrication period is determined by color coded activator screws.
• Depending on your application’s requirement, you may choose to discharge 120 cm³ in a period of 1, 3, 6 or 12 months.
• The activator screw generates pressure (max. 4 bar) which moves the piston forward and continuously injects small lubricant amounts into the lubrication point
• Perma CLASSIC is fully dust and water proof and can withstand impacts and accidental knocks.

Note: For each Classic 120 dispenser you need an activator screw, which you can order under the links below:
