Description
- 3M™ Scotch-Weld™ Structural Epoxy Adhesive EC-9323-2 B/A is a thixotrophic, sag-resistant, two component epoxy paste adhesive which cures at room temperature or with mild heat to form a tough, impact resistant structural bond.
- It has an excellent adhesion to a wide variety of substrates such as metals, glass, ceramics and plastics, incl. GFRP and CFRP.
- Once cured it provides very high shear and peel strength over a wide temperature range, with excellent resistance to harsh environments and chemicals commonly encountered in aerospace applications.
- Typical applications are aircraft interior panel bonding, ditch and pot, insert, or bracket bonding. The product is available in a white and a black version.
- Content: 200 ml
- Colour: black
Highlights
- Thixotrophic, non- sag, full room temperature processable,
- Available in duo-pack cartridge for easy and best processing.
- Toughened system providing very high shear and peel strength
- Excellent environmental resistance
Technical specifications
The following technical information and data should be considered representative or typical only and should not be used for specification purpose.
| General Properties | Part B | Part A |
| Color | White or Black | Off-white |
| Base | Modified epoxy | Modified amine |
| Consistency | Thixotropic paste | Thixotropic paste |
| Density | 1.04 g / cm³ | 1.03 g / cm³ |
| Solids | 100 % | 100 % |
| Viscosity | 250 Pas | 75 Pas |
| Mix ratio by weight (by volume) | 100 : 50 wt. (100 : 50 vol.) | 100 : 50 wt. (100 : 50 vol.) |
| Work life and open time at 23 ± 2 °C | > 120 minutes | > 120 minutes |
| Handling strength | 4 hours | 4 hours |
| Full cure cycle | 7 days at room temperature | 7 days at room temperature |
Hazard Information (CLP)
Signal word: Danger (Part A) / Warning (Part B)
Hazard Statements (H phrases)
- H314: Causes severe skin burns and eye damage. (Part A)
- H315: Causes skin irritation. (Part B)
- H317: May cause an allergic skin reaction. (Both Parts)
- H319: Causes serious eye irritation. (Part B)
- H336: May cause drowsiness or dizziness. (Part A)
- H410: Very toxic to aquatic life with long lasting effects. (Part A)
- H411: Toxic to aquatic life with long lasting effects. (Part B)
Safety Instructions (P phrases)
Prevention:
- P260B: Do not breathe dust. (Part A)
- P273: Avoid release to the environment. (Both Parts)
- P280B: Wear protective gloves/eye protection/face protection. (Part A)
- P280E: Wear protective gloves. (Part B)
Response:
- P303 + P361 + P353: IF ON SKIN (or hair): Take off immediately all contaminated clothing. Rinse skin with water/shower. (Part A)
- P305 + P351 + P338: IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing. (Both Parts)
- P310: Immediately call a POISON CENTER or doctor/physician. (Part A)
- P333 + P313: If skin irritation or rash occurs: Get medical advice/attention. (Part B)
- P391: Collect spillage. (Part B)
Additional Hazard Information
- EUH212: Warning! Hazardous respirable dust may be formed when used. Do not breathe dust. (Both Parts)
Other Hazards
- Individuals sensitized to amines may experience cross-sensitization with other amines. (Part A)
- This material does not contain substances that are considered PBT or vPvB. (Both Parts)
Hazardous materials. The forwarding charges may be raised, if shipping to: DE, AT, NL, GB, CH, CZ, IT, ES, FI, NO, BE, IE, RO, PL, FR, PT, LU, DK, LI, GR, SE, SK, BG, SI, CA, LT, EE, LV, HR, SA,
3M Deutschland GmbH, Carl-Schurz-Straße l, 41453 Neuss, Deutschland, 02131-14-2914 / 0, [email protected], www.3m.com/msds
