Weicon AN 302-72 High-temperature Threadlocker high strength red 20 ml

(8 customer reviews)

24,22 €

WEICONLOCK AN 302-72 is a high-strength locking compound for thread connections and stud bolts with high temperature resistance from -60°C to 230°C.

Quick Product Inquiry

Send us a quick inquiry for this product. We will reply with availability, pricing, and delivery information.

SKU: ID7fd15209c7 Category:

Description

WEICONLOCK® AN 302-72 Locking of Threads and Stud Bolts
  • Higher viscosity
  • High strength
  • Hard to disassemble
  • Temp. resistance in °C, from: -60 °C
  • Temp. resistance in °C, up to: 230 °C
  • Pack size: 20 ml pen-system
  • Also available in: 50 ml and 200 ml pen-system
Surface pre-treatment
  • To achieve optimum results, the mounting parts should be degreased and cleaned, e.g. with WEICON Surface (roughen the surfaces, if required).
  • WEICONLOCK can also be used on uncleaned surfaces, e.g. screws as delivered. However, the cleaner the surface, the better the results achieved.
Processing
  • WEICONLOCK is applied evenly straight from the Pen with the help of the dosing tip; avoid direct contact between dosing tip /metal.
  • For sealing applications, apply WEICONLOCK to the thread in circles.
  • Assemble parts and screw tight.
  • Do not pour any WEICONLOCK back into the bottle that has already come into contact with metal.
  • Even extremely small metal particles cause the adhesive to cure inside the bottle. Therefore, in serial production, the use of dosing devices is recommended.
Storage
  • WEICONLOCK has a shelf life of at least 24 months, when stored at room temperature in closed original container.
  • Protect from heat sources and direct sunlight.
  • The air contained in the Pen keeps WEICONLOCK liquid.
Instructions for use
  • When using WEICON products, the physical, safety-related, toxicological and ecological data and regulations in our EC safety data sheets (www.weicon.com) must be observed.
Technical specification.
Colour red
Fluorescent no
For thread connections up to M 56 R 2″
Viscosity 6.000 – 15.000 mPa·s
Gap bridging up to max. 0,3 mm
Breakaway torque 20 – 30 Nm
Prevail torque 40 – 75 Nm
Shear strength Nmm² (DIN 54452) 10 – 15 N/mm²
Handling strength 20 – 40 min.
Final strength (100 % strength) 5-10 h
Temperature resistance -60°C to +230°C
Compressive strength (free cutting steel / grub screw = 8.8) M3x6 max. 1500 bar
M4x6 max. 1500 bar
M5x8 max. 1000 bar
M6x10 max. 700 bar
M8x12 max. 500 bar
M10x16 max. 300 bar
Approvals / Guidelines Hygiene Institute UBA KTW-BWGL




Hazard Information (CLP)



Signal word: Danger

Hazard Statements (H-phrases)
  • H315: Causes skin irritation.
  • H317: May cause an allergic skin reaction.
  • H318: Causes serious eye damage.
  • H413: May cause long lasting harmful effects to aquatic life.
Precautionary Statements (P-phrases)
Prevention:
  • P280: Wear protective gloves. Wear eye or face protection.
  • P273: Avoid release to the environment.
  • P261: Avoid breathing vapor.
  • P264: Wash thoroughly after handling.
Response:
  • P362+P364: Take off contaminated clothing and wash it before reuse.
  • P302+P352: IF ON SKIN: Wash with plenty of water.
  • P333+P313: If skin irritation or rash occurs: Get medical advice or attention.
  • P305+P351+P338, P310: IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing. Immediately call a POISON CENTER or doctor.
Storage:
  • Not applicable.
Disposal:
  • P501: Dispose of waste according to applicable legislation.
Information on product safety (Manufacturer, Contact)

WEICON GmbH & Co. KG, Königsberger Strasse 255, 48157 Münster, GERMANY, +49 251 9322-0, [email protected], www.weicon.de
