Description
Product Details
RS PRO Black Epoxy Potting Compound plus Hardener 500 g Twin Pack.
From RS PRO we offer you this easy to use and mix two-part black epoxy resin potting compound. The epoxy resin potting compound designed for general purpose use but is specifically excellent for use LED and outdoor environments plus importantly is flame-retardant meeting ROHS / UL94 V-O approval.
The all-round protection supplied by the epoxy resin potting compound is not only flame -retardant it is resistant to chemicals and water providing you with an excellent hard coating protection to your components. The posting compound, supplied as a twin pack, two compartments, one with the epoxy resin and the other contains the hardener. So simple to mix-together, just open the bag then remove the central clip and mix. The RS PRO datasheet not only explains how to mix the potting compound there are also easy to follow diagrams.
FEATURES & BENEFITS
- Flame retardant to UL94 V-0 includes Clean Flame retardant technology.
- Mix in the bag twin pack design, no user contact.
- 500 g pack size
- High hardness potting compound – 85 Shore D.
- Excellent protection against vibration and physical shock.
- Chemical and water resistant.
- Low shrinkage ratio during the 24-hour curing process.
- Coefficient expansion 40 ppm/°C.
- Dielectric strength 16.6 kV/mm.
- Thermal conductivity 0.45 W/mK.
- Viscosity 000 mPa/s at 25°C, 9.
- Tensile strength 60 MPa.
- ROHS / UL94 Certification.
- Meets UL94 V-0 Flame retardancy.
APPLICATIONS
- General purpose.
- Outdoor applications.
- LED Applications.
- Electrical components applications.
Why RS PRO?
RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards; theyre only given the RS PRO seal of approval if were confident of their exceptional quality, which means you can be confident too.
Specifications
| Product Material | Epoxy |
|---|---|
| Package Type | Pack |
| Package Size | 500 g |
| Special Properties | Flame Retardant |
| Cure Time | 24 h |
| Hardness | 85 Shore D |
| Thermal Conductivity | 0.45W/mK |
| Colour | Black |
| Maximum Operating Temperature | 120°C |
| Minimum Operating Temperature | -40°C |
| Physical Form | Viscous Liquid |
| Volume Resistivity | 9000 mPa∙s @23°C |
| Viscosity Description | High Viscosity |
| Odour | Characteristic |
| Dielectric Strength | 16.6kV/mm |
| Operating Temperature Range | -40°C to 120°C |
| Viscosity Measurement | 000 mPa/s @ 25°C, 9 |
| Chemical Composition | Epoxy Resin |
