Perma NOVA LC125 Lubricant cartridge with Klubersynth UH1 14-151

Perma NOVA LC125 Lubricant cartridge with Klübersynth UH1 14-151

Kluber Klübersynth UH1 14-151

• Synthetic lubricating grease for the food and pharmaceutical processing industry
• Good corrosion protection reduces the risk of premature bearing failure
• Good pumpability in centralized grease system prevents grease starvation
• For a wide service temperature range due to the soft consistency of the grease
• ISO 21469 certified – supports the compliance with the hygienic requirements in your production.

Technical specifications

NSF-H1 registration	056 354
Lower service temperature	-45 °C / -49 °F
Upper service temperature	120 °C / 248 °F
Speed factor (n x dm)	approx. 500 000 mm/min
NLGI grade, DIN 51818	1
Worked penetration, DIN ISO 2137, 25 °C, upper limit value	340 x 0.1 mm
Worked penetration, DIN ISO 2137, 25 °C, lower limit value	310 x 0.1 mm
Flow pressure of lubricating greases, DIN 51805, test temperature:-45 °C	<= 1 400 mbar
Density at 20 °C	approx. 0.89 g/cm³
Drop point, DIN ISO 2176	>= 250 °C
Texture	homogeneous
Color space	beige
Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the unopened  original container, approx.	24 months

Applications

• Used for machines and equipment in the food processing and pharmaceutical industry, particularly for lubrication points that may have incidental and technically unavoidable contact with the food product. However, we recommend using Klübersynth UH1 14-151 at all lubrication points, in order to avoid problems due to lubricant contamination.
  This special grease lubricates rolling and sliding bearings, lifting cylinders, joints, guide bars, cams, etc.

---

​Perma NOVA Lubrication systems

• Perma NOVA can be used in all application areas from -20 °C to +60 °C.
• A discharge period from 1 to 12 months can be entered via the setting button on the NOVA Control unit.
• The control unit then calculates the required quantity of gas for constant and reliable discharge while taking into account the ambient temperature.
• Perma NOVA consists of a reusable control unit, a NOVA LC filled with grease or oil and a protective cover.
• NOVA LC is available in 65 cm³ and 125 cm³.

Information on product safety (Manufacturer, Contact)

perma-tec GmbH & Co. KG, Hammelburger Str. 21, 97717 Euerdorf, Deutschland, +49 9704 609-0, [email protected]
