Perma FUTURA 120 Lubricant dispenser with Fuchs Gleitmo SIL 115 M

Perma FUTURA 120 Lubricant dispenser with grease Fuchs Gleitmo SIL 115 M | N° 119446

GLEITMO SIL 115 M  High-temperature silicone grease with organic thickener NLGI 2

Application

GLEITMO SIL 115 M is particularly suitable for high temperature applications such as, for example, in wheel hubs of wagons in brickworks, hot air ventilators, conveying devices and door hinges in drying furnaces, foundries, control and monitoring equipment in vulcanising works. In addition GLEITMO SIL 115 M acts as slip agent for hot-formed plastic parts.

Industries

• Casting
• Machinery, equipment
• Power generation
• Other industries

Technical data

• Colour: White
• Thickener: Polyurea
• Dropping point °C: ≥ 300
• Worked penetration (Pw 60) 0,1 mm: 265 – 295
• NLGI-class: 2
• Water resistance eval.-stage: 1 – 90
• Oil separation at
  • 40°C / 18h %: ≤ 1
  • 40°C / 7d %: ≤ 4
• Base oil viscosity at
  • 40°C: 80 mm²/s
  • 100°C: 18 mm²/s
• Temperature range: -30 up to +220 °C
  • short- term: +250 °C

Perma FUTURA Lubricant dispenser

• Perma FUTURA is a single-point lubrication system for roller- and sliding bearings, sliding guides, open gears, gear racks, spindles, shaft seals, chains, etc.
• Operates at ambient temperatures between 0 up to +40 °C.
• Perma FUTURA has a corrosion-proof plastic housing which makes it ideal for hygienically clean applications (e. g. food and chemical industry).
• The reliable operating principle is based on an electrochemical reaction.
• The lubrication period is determined by color coded activator screws.
• Depending on your application’s requirement, you may choose to discharge 120 cm³ in a period of 1, 3, 6 or 12 months.
• The activator screw generates pressure (max. 4 bar) which moves the piston forward and continuously injects small lubricant amounts into the lubrication point
• Quick and easy exchange without special tools

Note: For each FUTURA dispenser you need an activator screw, which you can order under the links below:
