Perma Flex M125 Lubricant dispenser with Petamo GHY 133 N

Perma Flex M125 Lubricant dispenser with Klüber Petamo GHY 133 N | N° 107192

Perma Flex M125 Lubricant dispenser

• The automatic lubrication system perma FLEX is available in two convenient sizes (60 cm³ / 125 cm³).
• It can be used for inside or outside applications at temperatures ranging from -20 °C to +60 °C.
• Discharge period setting is flexible and can be adjusted from 1 – 12 months using the dial on top of the lubricator.
• Perma FLEX comes fully assembled and ready-to-use. Simply turn the dial to the desired discharge period and the system is activated.
• The electronically controlled chemical reaction will build up the pressure that is necessary to continually supply the lubrication point with fresh lubricant.

Klüber Petamo GHY 133 N Long-term and high-temperature grease for rolling bearings

• Resistance to high temperatures
• High resistance to oxidation
• Efficient wear protection even at high temperatures
• Good corrosion protection
• Good water resistance
• Reduced maintenance due to lifetime lubrication
• Wide service temperature range allows a variety of applications
• Reliable operation and long service life due to excellent protection against wear and corrosion, especially in water pump bearings and clutch release bearings

Technical specifications

• Chemical composition, type of oil: synthetic hydrocarbon oil
• Chemical composition, type of oil: mineral oil
• Chemical composition, thickener: polyurea
• Lower service temperature: -40 °C / -40 °F
• Upper service temperature: 160 °C / 320 °F
• Colour space: brown
• Density at 20 °C: approx. 0.90 g/cm³
• Worked penetration, DIN ISO 2137, 25 °C, lower limit value: 265 x 0.1 mm
• Worked penetration, DIN ISO 2137, 25 °C, upper limit value: 295 x 0.1 mm
• Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C: approx. 165 mm²/s
• Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C: approx. 18 mm²/s
• Drop point, DIN ISO 2176, IP 396: >= 250 °C
• Speed factor (n x dm): approx. 500 000 mm/min

Applications

Rolling bearings in

• Electric motors
• Fan heaters
• Drying installations
• Textile machines
• Paper machines

Automotive components, e.g.

• Belt tensioning rollers (rotating outer ring)
• Couplings
• Water pumps
• Fans
• Wheel bearings

---

Hazard statements (CLP)

Signal word: Warning

Hazard statements (H-phrases)

• H410: Very toxic to aquatic life with long lasting effects.

Safety precautions (P-phrases)

Prevention:

• P273: Avoid release to the environment.

Response:

• P391: Collect spillage.

Additional labeling (EUH-phrases)

• EUH208: Contains condensation products of fatty acids, tall oil with 2-amino-2-ethylpropanediol. May cause allergic reactions.

Storage and disposal

• This substance/mixture contains components classified as persistent, bioaccumulative and toxic (PBT) or very persistent and very bioaccumulative (vPvB).
• This substance/mixture contains components identified under Article 57(f) of the REACH regulation, Commission Regulation (EU) 2018/605, or Commission Delegated Regulation (EU) 2017/2100 as endocrine-disrupting for the environment.

Other relevant information

• This substance/mixture contains no components with endocrine-disrupting properties according to REACH Article 57(f) or Commission Delegated Regulation (EU) 2017/2100 or 2018/605 in concentrations of 0.1% or more.

Klüber Petamo GHY133N, Petamo GHY 133N, GHY-133-N, GHY-133 N

Information on product safety (Manufacturer, Contact)

perma-tec GmbH & Co. KG, Hammelburger Str. 21, 97717 Euerdorf, Deutschland, +49 9704 609-0, [email protected]
