Perma CLASSIC 120 Single-point lubricator with grease Hyspin DSP 46

Perma CLASSIC 120 Lubricant dispenser with Hyspin DSP 46 | N° 100508

Hyspin DSP 46 Detergent Hydraulic Oil

• High thermal stability.
• Reliable corrosion protection.
• Excellent oxidation stability.
• Good emulsifying and detergency properties.
• Excellent air separation capability.
• Excellent filterability.
• Good low temperature behaviour.
• General good compatibility with elastomers.
• Free of silicone.

Technical specifications

• ISO Viscosity Grade: 46
• Density @ 15°C / 59°F: 880
• Kinematic Viscosity @ 40°C / 104°F: 46
• Kinematic Viscosity @ 100°C / 212°F: 6.8
• Viscosity Index: 102
• Flash Point – open cup method: 240/464
• Pour Point: -30/-22

Applications

• For hydraulics operating under high pressures and temperatures and additional high requirements on the deterging
  properties.

Perma CLASSIC 120 Automatic lubrication system

• Perma CLASSIC is a single-point lubrication system for roller- and sliding bearings, sliding guides, open gears, gear racks, spindles, shaft seals, chains, etc.
• Operates at ambient temperatures between 0 up to +40 °C.
• Typical applications can be found in mining, steel, automotive and mechanical engineering.
• The reliable operating principle is based on an electrochemical reaction.
• The lubrication period is determined by color coded activator screws.
• Depending on your application’s requirement, you may choose to discharge 120 cm³ in a period of 1, 3, 6 or 12 months.
• The activator screw generates pressure (max. 4 bar) which moves the piston forward and continuously injects small lubricant amounts into the lubrication point
• Perma CLASSIC is fully dust and water proof and can withstand impacts and accidental knocks.

Note: For each Classic 120 dispenser you need an activator screw, which you can order under the links below:
