Perma FLEX M125 Lubricant dispenser with high performance oil SO14

Perma Flex M125 Lubricant dispenser with oil SO14 | N° 107199

Perma High performance oil SO14

• High-temperature chain oil
• Efficient lubrication even at high operating temperatures
• Good regeneration effect on used oil
• Favorable viscosity-temperature properties for safe cold starts
• Outstanding penetration properties for rapid formation of the lubricating film
• Good adhesion, no throwing off
• Resistance to wear and pressure
• Little residue owing to fully synthetic constituents
• Efficient against the settling of finishing and softening compounds and their condensates at the point of friction

Technical specifications

• Chemical composition, type of oil: ester oil
• Chemical composition, type of oil: synthetic hydrocarbon oil
• Upper service temperature: 250 °C / 482 °F
• Appearance: clear
• Density, DIN 51757, 20 °C: approx. 0.95 g/cm³
• Colour space: green
• Flash point, DIN EN ISO 2592, Cleveland, open-cup apparatus: >= 220 °C
• Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C: approx. 28 mm²/s
• Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C: approx. 320 mm²/s
• Viscosity index, DIN ISO 2909: >= 110

Applications

• Perma High performance oil SO14 is suitable for all oil-lubricated tenter chains such as roller chains, chains or clips with ball bearings in cases of combined lubrication of bearings, chain joints and slide ways), and slide chains with lubrication of slide rails, chain joints and bolts in equalizing frames, single-layer tenters, tier tenters, festoon driers and steamers as well as installations.

Perma Flex M125 Lubricant dispenser

• The automatic lubrication system perma FLEX is available in two convenient sizes (60 cm³ / 125 cm³).
• It can be used for inside or outside applications at temperatures ranging from -20 °C to +60 °C.
• Discharge period setting is flexible and can be adjusted from 1 – 12 months using the dial on top of the lubricator.
• Perma FLEX comes fully assembled and ready-to-use. Simply turn the dial to the desired discharge period and the system is activated.
• The electronically controlled chemical reaction will build up the pressure that is necessary to continually supply the lubrication point with fresh lubricant.

Information on product safety (Manufacturer, Contact)

perma-tec GmbH & Co. KG, Hammelburger Str. 21, 97717 Euerdorf, Deutschland, +49 9704 609-0, [email protected]
