Description
Tube up to +100 °C oØ 8 mm x iØ 5 mm for PRO | N° 101569
- Material: Polyamide 12W
- Color: black
Dimensions
- Outer diameter: 8 mm
- Inner diameter: 5 mm
- Wall thickness: 1,5 mm
- Length: per meter available (For custom length, please contact us here)
Mechanical properties
- Highly resistant to stress cracking, pressure and impact. high mechanical strength
Chemical resistance
- Resistant to most oils, greases, fuels, organic solvents, diluted acids, alkaline solutions and salts
Technical data
- Max. operating pressure at +20 °C: 31 bar
- Bursting pressure at +20 °C: 93 bar
- Minimum bending radius at +20 °C: 45 mm
- Operating temperature range: -35 °C bis +100 °C
- Flammability class UL94: HB
- Absence of PWIS: Confirmed
- Absence of silicone: Confirmed
- Absence of halogen: Confirmed
- Drag chain suitability: Min. bending radius of 10x tube-Ø
