Description
Tube up to +260 °C oØ 8 mm x iØ 6 mm PTFE | N° 101394
- Material: PTFE
- Color: translucent
Dimensions
- Outer diameter: 8 mm
- Inner diameter: 6 mm
- Wall thickness: 1 mm
- Length: per meter available
Mechanical properties
- Good temperature resistance, noncombustible
Chemical resistance
- Resistant to all liquid, gaseous and corrosive media, including all acids, alkaline solutions, solvents, oils and
fuels. - PTFE tubes are suitable for food an beverages as they are unflavored an not toxic.
Technical specifications
- Max. operating pressure at +20 °C: 9 bar / 130 psi
- Minimum bending radius at +20 °C: 50 mm
- Operating temperature range: -70 °C to +260 °C
- Flammability class UL94: V-0 incombustible
- Absence of PWIS: Confirmed
- Absence of silicone: Confirmed
- FDA: Confirmed
- Drag chain suitability: Min. bending radius of 10x tube-Ø
perma-tec GmbH & Co. KG, Hammelburger Str. 21, 97717 Euerdorf, Deutschland, +49 9704 609-0, [email protected]
