Description
Klübertemp YV 93-92 Sliding agent for valves, fittings and installations carrying oxygen under medium partial pressure | N° 013071
- Klübertemp YV 93-92 is a white sliding agent with good wetting ability based on perfluorinated polyether and solid lubricants.
- It offers medium oxygen pressure surge resistance and high resistance to a wide range of chemicals.
- To ensure continuous adherence to this high quality standard, Klübertemp YV 93-92 is manufactured in small series subject to strict hygiene requirements and each batch is inspected based on M 034-1 List of nonmetallic materials (213-075).
- Temperature range: -60°C to +160°C
- Size: 1kg can
Benefits for your application
- Reliable operation of installations and components using gaseous oxygen
- due to medium oxygen pressure surge resistance (see product data)
- due to good compatibility with most materials used in this branch of industry
- due to a wide service temperature range, in particular for low temperatures
- Also suitable for installations and components carrying liquid oxygen
- Each product batch is checked for its reactivity to oxygen
Applications
- Klübertemp YV 93-92 is used as a sliding agent for the lubrication of valves, fittings and installtions carrying gaseous and/or liquid oxygen for chemical plants and apparatus requiring high resistamce tp various gases (conclusion by analogy based on chemical composition).
- The wide service temperature range, in particular at low temperatures, underlines the universal application possibilities of this sliding agent
- Possible applications are:
- Oxygen valves
- Peripheral aggregates of chemical installations –
- Hose couplings, e.g. oxygen pipe connections, bolts, slideways, etc.
- Assembly aid for most rubber-elastic materials and plastics
- For industrial handling, maintenance and care of oxygen components
Application notes
- All surfaces to be wetted must be thoroughly cleaned prior to product application.
- The friction / lubrication points of surfaces / components must be clean and bright (i.e. free from oil, grease, dirt particles or perspiration).
- We recommend cleaning the surfaces with clean white spirit and then Klüberalfa XZ 3-1, ensuring residue-free surfaces when dried.
- For valves and installations carrying oxygen, the application procedure must also be “oxygen clean” in order to attain a “ready for oxygen service” condition.
Technical specifications
| Chemical composition, type of oil | PFPE |
| Colour space | white |
| NLGI grade, DIN 51818 | 2 |
| Texture | homogeneous |
| Chemical composition | solid lubricant |
| Density at 20 °C | ca. 1,99 g/cm³ |
| Copper corrosion, DIN 51811, (lubricating grease), 24h/100°C | 1 – 100 corrosion degree |
| Flow pressure of lubricating greases, test temperature: -60 °C | <= 500 mbar |
| Lower service temperature | -60 °C |
| Upper service temperature | 160 °C |
Hazard Statements (CLP)
Signal word: Danger
Hazard Statements (H-phrases)
- H411: Toxic to aquatic life with long lasting effects.
Safety Instructions (P-phrases)
Prevention:
- P273: Avoid release to the environment.
Response:
- P391: Collect spillage.
Other Relevant Information
- This substance/mixture contains no components in concentrations of 0.1% or higher that are classified as persistent, bioaccumulative, and toxic (PBT) or very persistent and very bioaccumulative (vPvB).
- The substance/mixture contains no components in concentrations of 0.1% or more with endocrine-disrupting properties as defined under REACH Article 57(f) or Commission Delegated Regulations (EU) 2017/2100 or (EU) 2018/605.
