Description
BARRIERTA I S-402 High-temperature greases with good long-term characteristics NLGI 2 | N° 090005
- BARRIERTA is Europe’s oldest high-quality brand of high-temperature lubricants based on perfluorinated polyether oil (PFPE).
- BARRIERTA products are among the most widely used PFPE lubricants today.
- Temperature range: -40°C to +260°C
- Volume: 1 kg can
- Also available in: 800 g cartridge, 10 kg bucket, 180 kg barrel
Benefits for your application
- Long-term availability and service life of components
- over a wide service temperature range up to 260°C
- when exposed to aggressive chemical agents and vapours
- when using sensitive plastic materials
- Tried and tested over many years in numerous industries and component types
- due to BARRIERTA base oils, which are made specifically to enable long-term stability
- backed by a large number of approvals and references
- due to availability in 4 different viscosity grades to suit various applications
Applications
- BARRIERTA I greases attain long service lives when used in rolling and plain bearings operating under high thermal stress.
- The fine thickener and the high oil content enable smooth running of bearings also at high speeds and ensure a long life of the lubricated components.
- Typical fields of application are in
- film stretchers
- textile stenter frames
- precision engineering
- clean-room engineering (e.g. microchip manufacture)
- The low vapour pressures of BARRIERTA I greases make them also recommendable for use in fine to ultra-high vacuum.
Application notes
- For optimum lubrication results, we recommend cleaning the friction points with white spirit 180/210 and then Klüberalfa XZ 3-1. For initial lubrication, the friction point must be clean and bright and free from particles.
Technical specifications
| Manufacturer number | 0900050037 |
| Composition, solid lubricant | PTFE |
| Colour space | white |
| Service temperature, lower limit | -40 °C |
| Service temperature, upper limit | 260 °C |
| Density, Klüber method: PN 024, 20°C | approx. 1.95 g/cm³ |
| NLGI grade, DIN 51818 | 2 |
| Kinematic viscosity of the base oil, DIN EN ISO 3104 / DIN 51562-1 / ASTM D445 / ASTM D7042, 100°C |
approx. 40 mm²/s |
| Kinematic viscosity of the base oil, DIN EN ISO 3104 / DIN 51562-1 / ASTM D445 / ASTM D7042, 40°C |
approx. 420 mm²/s |
| Flow pressure, DIN 51805-2, -40°C | ≤ 1400 mbar |
| Four-ball tester, welding load, DIN 51350-4 | approx. 5000 N |
| Speed factor (n x dm) | 300000 mm/min |
BARRIERTA IS-402, BARRIERTA I S 402
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
