Description
White lubricating and assembly paste for the food-processing and pharmaceutical industries
- Klüberpaste UH1 84-201 is a white lubricating and assembly paste for versatile lubricating and assembly purposes in hygienically sensitive environments.
- It contains fully synthetic base oils and a special blend of organic and inorganic thickeners.
- Klüberpaste UH1 84-201 is water-resistant and provides good corrosion protection. It is therefore suitable for friction points affected by humidity which normally require the use of special products.
- Klüberpaste UH1 84-201 is NSF H1 registered and therefore complies with FDA 21 CFR § 178.3570. The lubricant was developed for incidental contact with products and packaging materials in the food-processing, cosmetics, pharmaceutical or animal feed industries. The use of Klüberpaste UH1 84-201 can contribute to increase reliability of your production processes. We nevertheless recommend conducting an additional risk analysis, e.g. HACCP
- Content: 500g cartridge
Highlights
- Reliable adhesion to the friction point, also when subject to humidity
- Good compatibility with high-alloy steels
- ISO 21469 certified – supports the compliance with the hygienic requirements in your production. You will find further information about ISO Standard 21469 on our website www.klueber.com
Application
- Klüberpaste UH1 84-201 is generally suitable for almost all friction points in the food-processing and pharmaceutical industries
- As an assembly paste for transition and loose fits to prevent fretting corrosion
- As a long-term lubricant for low-speed guide rails, hinges, rollers, chains, etc
Technical specifications
| Article number | 5113 |
| NSF-H1 registration | 136 305 |
| Lower service temperature | -45 °C / -49 °F |
| Upper service temperature | 120 °C / 248 °F |
| Colour space | white |
| NLGI grade, DIN 51818 | 1 |
| Kinematic base oil viscosity, DIN 51562, part 01/ASTM D-445/ASTM D 7042, 40 °C (no polymer content) | approx. 200 mm²/s |
| Kinematic base oil viscosity, DIN 51562, part 01/ASTM D-445/ASTM D 7042, 100 °C (no polymer content) | approx. 22 mm²/s |
| Corrosion inhibiting properties of lubricating greases, DIN 51802, (SKF-EMCOR), test duration: 1 week, distilled water | <= 1 corrosion degree |
| Friction coefficients screw test, screw M 10×30-8.8, DIN EN ISO 4017, black and nut M 10-8, DIN EN ISO 4032, polished, averaged thread friction coefficient (first-time tightening) | 0.1 |
| Friction coefficients screw test, screws M 10×30-8.8, DIN EN ISO 4017, black and nut M 10-8, DIN EN ISO 4032, bright, averaged head friction coefficient (first-time tightening) | 0.1 |
| Friction coefficients screw test, screw M 10×30-8.8, DIN EN ISO 4017, black and nut M 10-8, DIN EN ISO 4032, polished, standard deviation thread friction coefficient (first-time tightening) | 0.011 |
| Friction coefficients screw test, screw M 10×30-8.8, DIN EN ISO 4017, black and nut M 10-8, DIN EN ISO 4032, polished, standard deviation head friction coefficient (first-time tightening) |
0.015 |
| Four-ball tester, welding load, DIN 51350 pt. 04 | >= 3 000 |
| Water resistance, DIN 51807 pt. 01, 3 h/90 °C, rating | <= 1 – 90 |
| Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the unopened original container, approx. | 36 months |
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
