Klüberoil GEM 1-46 N High-performance multipurpose oil 5L

Klüberoil GEM 1-46 N

Klüberoil GEM 1 N is a high-performance and multipurpose oil based on selected mineral oils satisfying the growing requirements and increasing power density of modern gears. Klüberoil GEM 1 N includes KlüberComp Lube Technology*, i.e. it is based on especially high-grade raw materials and advanced additives, enabling maximum performance in the lubrication of all gear components

Characteristics

• High scuffing protection
• Excellent wear protection for gears and rolling bearings
• Good shear stability for reliable lubricant film formation
• High micropitting resistance
• Excellent ageing and oxidation resistance
• Low foaming tendency
• Good elastomer compatibility
• Approvals by numerous gear OEMs
• Volume: 5l canister
• Available in 400ml spray can, 5l canister, 200l barrel

Field of application

• friction points subject to high loads in spur
• bevel and worm gears
• rolling and sliding bearings
• spindles, chains, guideways
• joints and toothed couplings

Technical specifications

• Lower service temperature: -15 °C
• Upper service temperature: 100 °C
• Density, based on DIN 51757) at 15 °C: approx. 870 kg/m³
• Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C: approx. 46 mm²/s
• Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C: approx. 7 mm²/s
• Viscosity index, DIN ISO 2909: >= 90
• ISO viscosity grade, DIN ISO 3448: 46
• Flash point, DIN EN ISO 2592, Cleveland, open-cup apparatus: >= 200 °C
• Pour point, DIN ISO 3016: <= -20 °C
• Foam test, ASTM-D 892, ISO 6247, sequence I/24 °C: <= 100/10 ml
• Foam test, ASTM-D 892, ISO 6247, sequence II/ 93.5 °C: <= 100/10 ml
• Foam test, ASTM D 892, ISO 6247, sequence III/24°C: <= 100/10 ml
• Ageing properties, ASTM D 2893, increase in viscosity: <= 6 %
• FZG scuffing test, DIN ISO 14635-1, A/8.3/90, scuffing load stage: >= 14
• FZG scuffing test, based on DIN ISO 14635-1, A/16.6/90, scuffing load stage: >= 12
• FAG FE8 rolling bearing test, DIN 51819-3, D 7,5/80-80, wear of rolling element: < 5 mg
• FAG FE8 rolling bearing test, DIN 51819-3, D 7,5/80-80, wear of cage: <= 200 mg
• Anticorrosive properties on steel, DIN ISO 7120, method A, steel, 24 h/60 °C: no rust corrosion degree
• Copper corrosion, DIN EN ISO 2160, 3 h/100 °C: 1 – 100 corrosion degree
• Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the unopened original container, approx: 60 months


KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
