Description
GRAFLOSCON B-SG 00 ULTRA
- GRAFLOSCON B-SG 00 ULTRA is a sprayable running-in lubricant with a mineral base oil. It contains aluminium stearate as a thickener and solid lubricant particles of fine graphite. The lubricant is free from bitumen, heavy metals, solvents and raw materials containing chlorine, and allows to subject the friction points to well-defined wear. GRAFLOSCON B-SG 00 ULTRA reduces surface roughness and improves the tooth flank quality
which makes it also suitable for corrective lubrication if tooth flanks are damaged. - Size: 25kg bucket,
- Available in 25kg bucket, 180kg drum
Benefits for your application
- GRAFLOSCON B-SG 00 ULTRA reduces surface roughness and improves tooth flank quality thus contributing to a longer service life of drives and reduced maintenance costs.
Application
- GRAFLOSCON B-SG 00 ULTRA was especially developed for specific running-in of open gears in rotary kilns, tube mills, and line blenders used in the cement, lime, gypsum, mining and chemical industries.
Technical specifications
| Article number | 39070 |
| Solid lubricants, percentage | approx. 12 % by weight |
| Colour space | black |
| Texture | homogeneous |
| Texture | long-fibred |
| Density at 20 °C | approx. 1.00 g/cm³ |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C | approx. 500 mm²/s |
| NLGI grade, DIN 51818 | 0 |
| Thermal stability of the lubricating film | approx. 200 °C |
| Functional lubricant film | approx. -30 °C |
| Application in automatic spray systems | -15 – 90 °C |
| Drop point, DIN ISO 2176, IP 396 | > 90 °C |
| FZG scuffing test, based on DIN ISO 14635, A/2.76/50, change in weight | approx. 1,4 mg/kWh |
| FZG scuffing test, based on DIN ISO 14635, A/2,76/50, scuffing load stage | > 12 |
| Four-ball tester, welding load, DIN 51350 pt. 04 | >= 6 500 N |
| Water resistance, DIN 51807 pt. 01, 3 h/40°C | 0 – 40 |
| Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the unopened original container, approx. | 24 months |
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
