Klübermatic PRO with Microlube GB 0 Universal lubricant 500ccm

Klübermatic PRO 500 Cartridge with Microlube GB 0 for automatic multi-point lubrication systems PRO MP-6, PRO C MP-6, and PRO Line.

Klüber MICROLUBE GB 0​

• MICROLUBE GB 0 is a specialty grease based on mineral oil. It is highly pressure-resistant, provides excellent wear and corrosion protection, and offers good wettability and water resistance.

Benefits for Your Application

• High-performance universal grease
• High load-carrying capacity
• Excellent wear protection
• Good corrosion protection properties
• Compatible with central lubrication systems

Application Areas
MICROLUBE GB 0 is specifically designed for applications involving high-load friction points and mixed friction conditions. It is used as a universal grease for lubricating eccentric presses (e.g., Müller-Weingarten eccentric presses), highly loaded spur and bevel gears with steel/steel material pairings (e.g., non-oil-tight geared motors), slide and guide rails, as well as sump-lubricated rolling bearings.

Application Instructions

MICROLUBE GB 0 can be applied using a brush, spatula, grease gun, or via central lubrication systems.
Gear lubrication is possible in an oil bath up to circumferential speeds of approximately 3 m/s or in smaller gear units using forced-drop lubrication.

Product Data

Structure	Homogeneous
Color	Red
Appearance	Transparent
Density at 20°C	Approx. 0.90 g/cm³
Worked Penetration, DIN ISO 2137, 25°C, Lower Limit	355 x 0.1 mm
Worked Penetration, DIN ISO 2137, 25°C, Upper Limit	385 x 0.1 mm
Base Oil Viscosity at 40°C	Approx. 590 mm²/s
Base Oil Viscosity at 100°C	Approx. 31.5 mm²/s
Shear Viscosity at 25°C	Approx. 3,000 mPas
Drop Point, DIN ISO 2176	> 180 °C
Flow Pressure at -25°C, DIN 51805-2	< 1,400 mbar
FZG Wear Test, DIN ISO 14635, A/2,76/50	>= 12
Minimum Shelf Life (Stored in Dry, Frost-Free Conditions)	36 months

---

Klübermatic Pro Multi-Point Lubrication Systems

Klübermatic PRO MP-6 – Precise battery-operated multi-point lubrication system for up to 6 lubrication points
Depending on the dispensing period (from one day to 24 months), 250 cm³ or 500 cm³ of grease is delivered from up to six outlets to the lubrication point. Thanks to the pressure build-up of up to 25 bar, the grease is distributed directly without pressure loss, even when using hose lines up to 5 m in length.

Klübermatic PRO C MP-6 – Multi-point lubrication system with external control
In addition to the PRO MP-6, the Klübermatic PRO C MP-6 can be operated in an impulse-controlled manner. The lubrication impulse timing can be freely set via a programmable logic controller (PLC). Thanks to the pressure build-up of up to 25 bar, the grease is distributed directly without pressure loss, even when using hose lines up to 5 m in length. The Klübermatic PRO C MP-6 is powered directly by the system and can be controlled and monitored via integration with the PLC.

Klübermatic PRO LINE – Flexible multi-point lubrication system for linear guides
Klübermatic PRO LINE is a specialized multi-point lubrication system for linear guides using grease. The amount of lubricant per outlet is flexible, and the dispensing behavior can be precisely adjusted to meet manufacturer specifications. The PRO Lubricant Container (LC) is available in 250 cm³ or 500 cm³ and supplies lubrication points for up to two years. The high-pressure build-up allows remote mounting using hose lines up to 5 meters per outlet.

Technical Data

Volume	500 cm³
Length (L)	260 mm
Diameter (D)	92 mm
Weight (empty)	1.37 kg
Weight (filled with high-performance grease)	1.82 kg
Dispensing time	1 day to 12 months
Dispensing volume per lubrication impulse	0.5 cm³
Operating temperature range	-20 °C to +60 °C
Maximum pressure build-up	25 bar
Maximum hose length (inner diameter 5 mm)	5 m
Compatible lubricants	Greases up to NLGI class 2
Power supply	PRO B battery
Emission sound pressure level	< 70 dB(A)
Connection thread	G3/8
Protection class	IP 54

---

Hazard Statements (CLP)

Signal word: Warning.

Hazard Statements (H-Statements)

• H319: Causes serious eye irritation.

Precautionary Statements (P-Statements)

Prevention:

• P264: Wash skin thoroughly after handling.
• P280: Wear eye protection/face protection.

Response:

• P305 + P351 + P338: IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing.
• P337 + P313: If eye irritation persists: Get medical advice/attention.

Additional Labelling (EUH-Statements)

• EUH208: Contains dibutyl [[bis[(2-ethylhexyl)oxy]phosphinothioyl]thio]succinate. May produce an allergic reaction.

Information on product safety (Manufacturer, Contact)

KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
