Description
Special low-temperature greases
- ISOFLEX TOPAS L 32 and L 32 N have been designed for extremely low temperatures. These greases consist of a synthetic hydrocarbon oil and a special lithium soap. ISOFLEX TOPAS L 32 and L 32 N are resistant to ageing and oxidation and provide good corrosion protection as well as water resistance.
- ISOFLEX TOPAS L 32 N also contains a UV indicator, which ensures quality checking even with minimum quantity lubrication.
- Content: 1kg can
- Available in 370g cartridge , 400g spray, 1kg can, 25kg bucket, 170kg drum
Benefits for your application
- Exceed OEM requirements of -40 °C
- Long service life due to high corrosion protection and resistance to oxidation and ageing
- Many years of successful use in the automotive industry (specified and approved by most car manufacturers and component suppliers worldwide)
Application
- ISOFLEX TOPAS L 32 and L 32 N are especially used for the lubrication of small gears used in automotive engineering for electrical adjustment mechanisms, e.g. window lifters, sun
roofs, seats, headlamps, fan flaps. - Both products have been approved by renowned car manufacturers, such as
– Volkswagen VW TL 778 A
– Daimler DBL 6827.40 and
– Daimler DBL 6827.41. - ISOFLEX TOPAS L 32 and L 32 N can also be used for:
– guideways, bowden cables, door locks
– rolling bearings in small motors, fans, pumps
– tooth flanks in plastic/plastic gears (e.g. POM, PA and PBT)
or plastic/steel material combinations.
Technical specifications
| Article number | 4130 |
| Lower service temperature | -60 °C / -76 °F |
| Upper service temperature | 130 °C / 266 °F |
| Colour space | beige |
| Density at 20 °C | approx. 0,88 g/cm³ |
| Texture | homogeneous |
| Texture | short-fibred |
| NLGI grade, DIN 51818 | 2 |
| Worked penetration, DIN ISO 2137, 25 °C, lower limit value | 265 x 0,1 mm |
| Worked penetration, DIN ISO 2137, 25 °C, upper limit value | 295 x 0,1 mm |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C | approx. 17 mm²/s |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C | approx. 3,8 mm²/s |
| Shear viscosity at 25 °C, shear rate 300 s-1, equipment: rotational viscometer, lower limit value | 2 000 mPas |
| Shear viscosity at 25°C, shear rate 300 s-1, equipment:rotational viscometer, upper limit value | 4 500 mPas |
| Flow pressure of lubricating greases, DIN 51805-2, test temperature: -35 °C | <= 450 mbar |
| Drop point, DIN ISO 2176, IP 396 | >= 185 °C |
| Speed factor (n x dm) | 1 000 000 mm/min |
| Water resistance, DIN 51807 pt. 01, 3 h/90 °C, rating | <= 1 – 90 |
| Corrosion inhibiting properties of lubricating greases, DIN 51802, (SKFEMCOR), test duration: 1 week, distilled water | <= 1 corrosion degree |
| Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the unopened original container, approx. | 36 months |
Klüber ISOFLEX TOPAS L32N, L-32-N, L 32N, L32 N, L-32, 32-N
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
