Description
Klüberfluid NH1 CM 4-100 Spray Semi-dry lubricating fluid offering very good adhesion | N° 081367
- Klüberfluid NH1 CM 4-100 is a spray based on a fully synthetic hydrocarbon oil combined with a carefully selected, highperformance solid lubricant and additive package.
- We deliberately designed this product without mineral oil in order to minimise the risk of MOSH/MOAH contamination. If applied correctly, a semi-dry lubricating effect can be attained with this product.
- Klüberfluid NH1 CM 4-100 shows very good adhesion to surfaces and high load-carrying capacity. As it is also highly resistant to ageing and oxidation, the product enables longer relubrication intervals and hence lower lubricant quantities being required.
- Temperature range: -35°C to +180°C
- Volume: 400ml spray can
Benefits for your application
- NSF H1 registered for higher process reliability
- Reduction of lubricant quantities possible due to
- excellent resistance to ageing and oxidation
- very good penetration behaviour
- Reliable operation because of very good resistance to water, steam and cleaning agents
- The formulation does not contain any saturated and aromatic mineral oil components
Application
- The product can be used for the lubrication of chains, joints and guideways as well as of hinges and locks, even when exposed to media. It was especially developed for the food-processing and pharmaceutical industries.
- Due to its performance characteristics, Klüberfluid NH1 CM 4-100 Spray can also be used in other industries.
Application notes
- Please apply Klüberfluid NH1 CM 4-100 Spray evenly. For the product to provide its full effect, we recommend thorough cleaning of the lubrication point prior to application.
- If your production process does not allow cleaning, we will be pleased to support you in checking the miscibility of greases and determining relubrication intervals. Do not spray against naked flame or onto hot or incandescent objects. Keep away from ignition sources. Protect against direct sunlight and temperatures above 50 °C. Shake well before use.
Technical specifications
| Chemical composition, solid lubricant | PTFE |
| Chemical composition, type of oil | synthetic hydrocarbon oil |
| Colour space | white |
| Viscosity index, DIN ISO 2909 | 120 |
| ISO viscosity grade, DIN ISO 3448 | 100 |
| Density at 20 °C | approx. 0.86 g/cm³ |
| Pour point, DIN ISO 3016 | <= -40 °C |
| Flash point, DIN EN ISO 2592, Cleveland, open-cup apparatus | >= 240 °C |
| Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C | approx. 12.1 mm²/s |
| Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C | approx. 100 mm²/s |
| Lower service temperature | -35 °C / -31 °F |
| Upper service temperature | 180 °C / 356 °F |
| Four-ball EP tester, welding load, DIN 51350 part 2 | approx. 3 000 N |
Hazard Statements (CLP)
Signal word: Danger
Hazard Statements (H-phrases)
- H222: Extremely flammable aerosol.
- H229: Pressurized container: may burst if heated.
Precautionary Statements (P-phrases)
Prevention:
- P210: Keep away from heat, hot surfaces, sparks, open flames, and other ignition sources. No smoking.
- P211: Do not spray on an open flame or other ignition source.
- P251: Do not pierce or burn, even after use.
Storage:
- P410 + P412: Protect from sunlight. Do not expose to temperatures exceeding 50 °C/122 °F.
Hazardous materials. The forwarding charges may be raised, if shipping to: DE, AT, NL, GB, CH, CZ, IT, ES, FI, NO, BE, IE, RO, PL, FR, PT, LU, DK, LI, GR, SE, SK, BG, SI, CA, LT, EE, LV, HR, SA,
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
