Description
GRAFLOSCON CA 901 ULTRA Spray Adhesive lubricant containing graphite | N° 081229
- GRAFLOSCON CA 901 ULTRA, a solvent-containing mineral oil based adhesive lubricant with a high content of solids, is applied by spray can.
- This spray is extremely adhesive, resistant to high pressure, and has good anti-corrosion properties.
- Volume: 400ml spray can
Benefits for your application
- Extremely adhesive
- Resistant to high pressure
- Easy straightforward application
Application
- GRAFLOSCON CA 901 ULTRA is suitable for the lubrication of open gear drives, spur and bevel gears, toothed racks, slide ways, guide rails, fixing cams, adjusting spindles, cam disks, etc.
- It is also suitable for the external lubrication of chains and wire ropes but not for friction pulley ropes.
Application notes
- Application by spray can. Shake well before use. GRAFLOSCON CA 901 ULTRA must not be exposed to direct heat (sunlight, radiant heaters, open fire, etc.).
Technical specifications
| Colour space | black |
| Density at 20 °C | approx. 1.05 g/cm³ |
| Worked penetration, DIN ISO 2137, 25 °C, lower limit value | 310 x 0.1 mm |
| Worked penetration, DIN ISO 2137, 25 °C, upper limit value | 350 x 0.1 mm |
| Thermal stability of the lubricating film | <= 180 °C |
| Functional lubricant film | >= -20 °C |
| Drop point, DIN ISO 2176, IP 396 | >= 180 °C |
| Four-ball tester, welding load, DIN 51350 pt. 04 | approx. 4 400 N |
| Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the unopened original container, approx. | 24 months |
Hazard Statements (CLP)
Signal word: Danger.
Hazard Statements (H-Sentences)
- H222: Extremely flammable aerosol.
- H229: Pressurized container: May burst if heated.
- H304: May be fatal if swallowed and enters airways.
- H315: Causes skin irritation.
- H336: May cause drowsiness or dizziness.
- H411: Toxic to aquatic life with long-lasting effects.
Precautionary Statements (P-Sentences)
Prevention:
- P210: Keep away from heat, hot surfaces, sparks, open flames, and other ignition sources. No smoking.
- P211: Do not spray on an open flame or other ignition source.
- P251: Do not pierce or burn, even after use.
- P273: Avoid release to the environment.
Response:
- P301 + P310: IF SWALLOWED: Immediately call a POISON CENTER/doctor.
- P331: Do not induce vomiting.
Storage:
- P410 + P412: Protect from sunlight and do not expose to temperatures exceeding 50 °C/122 °F.
Hazardous materials. The forwarding charges may be raised, if shipping to: DE, AT, NL, GB, CH, CZ, IT, ES, FI, NO, BE, IE, RO, PL, FR, PT, LU, DK, LI, GR, SE, SK, BG, SI, CA, LT, EE, LV, HR, SA,
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
