Description
UNIMOLY C 220 Spray, High-pressure resistant, hygrosetting bonded coating | N° 081053
- UNIMOLY C 220 is a hygrosetting grey bonded coating with an MoS2 base (molybdenum disulfide) and an inorganic binding agent.
- UNIMOLY C 220 is a fluid, ready-to-use product containing a mixture of flammable solvents. Once applied and hardened, the bonded coating is very resistant to pressure and has a wide temperature range.
- Owing to its structure, UNIMOLY C 220 is particularly suitable for high-vacuum applications. Adhesion is very good on special steel, metal and electroplated surfaces.
- Temperature range: -180°C to +450°C
- Size: 400ml spray can
- Also available in: 1l can, 20l bucket
Benefits for your application
- Hygrosetting at room temperature
- Suitable for high pressures
- Resistant to low and high temperatures
- Suitable for vacuum applications
- Excellent adhesion on metals
- Suitable for materials susceptible to cold welding, e.g. special steel nuts and bolts
- Well-proven as an assembly aid
- Improves the running-in process
- Prevents stick-slip
Applications
- UNIMOLY C 220 reduces friction and wear in metal/metal sliding contacts. It prevents nuts and bolts from seizing, and ensures a uniform tightening moment and low friction.
- UNIMOLY C 220 is also used as a running-in agent, e.g. for gears. Other fields of application are clinch bolts, hinge and lock components, slideways, spindles and other slowly sliding components subject to high loads.
Application notes
- Stir or shake well before use. This also applies to the spray version. UNIMOLY C 220 can be applied by immersion, spraying or by brush. Other types of application are indicated upon request. The surfaces to be coated must be cleaned/ degreased and be completely free from oil, grease, water, corrosion and scale. When applying UNIMOLY C 220 by spraying, use a paint spray gun.
Technical specifications
| Article number | 081053 |
| Colour space | grey |
| Service temperature, lower limit | -180 °C |
| Service temperature, upper limit | 450 °C |
| Density, DIN EN ISO 2811-3, 20°C | approx. 1.08 g/cm³ |
| Yield with a tribo-film thickness, 10 µm | approx. 10 m²/l |
| Cross-cut adhesion, DIN EN ISO 2409, based on standard, Klüber method: PA 063 / material: test plate |
0 Gt |
| Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the unopened original container, approx. |
24 months |
Hazard Statements (CLP)
Signal word: Danger.
Hazard Statements (H-Sentences)
- H222: Extremely flammable aerosol.
- H229: Pressurized container: May burst if heated.
- H318: Causes serious eye damage.
- H336: May cause drowsiness or dizziness.
- H412: Toxic to aquatic life with long-lasting effects.
Precautionary Statements (P-Sentences)
Prevention:
- P210: Keep away from heat, hot surfaces, sparks, open flames, and other ignition sources. No smoking.
- P211: Do not spray on an open flame or other ignition source.
- P251: Do not pierce or burn, even after use.
- P280: Wear eye/face protection.
Response:
- P305 + P351 + P338 + P310: IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses if present and easy to do. Continue rinsing. Immediately call a POISON CENTER/doctor.
Storage:
- P410 + P412: Protect from sunlight and do not expose to temperatures exceeding 50 °C/122 °F.
Hazardous materials. The forwarding charges may be raised, if shipping to: DE, AT, NL, GB, CH, CZ, IT, ES, FI, NO, BE, IE, RO, PL, FR, PT, LU, DK, LI, GR, SE, SK, BG, SI, CA, LT, EE, LV, HR, SA,
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
