Description
HOTEMP SUPER CH 2-100 Synthetic high-temperature chain oil | N° 002136
- HOTEMP SUPER CH 2-100 is a synthetic high-temperature chain oil based on a low-viscous, solvent-free and thermally stable ester oil.
- The special additives contained in HOTEMP SUPER CH 2-100 ensure good wear protection and lubricity.
- HOTEMP SUPER CH 2-100 has only low evaporation losses at high operating temperatures.
- Temperature range: 0°C to +250°C
- Volume: 20l canister
- Also available in: 200l drum
Benefits for your application
- Maximum machine life even at high operating temperatures due to good lubricating, spreading and wetting properties
- Reduced oil consumption and fume formation due to low evaporation losses at high temperatures
- Regenerates and dissolves pasty oil residues, hence less maintenance and unobstructed lubricating systems
- Reduced operating costs and low current consumption of electric drives due to low friction and wear values
Application
- HOTEMP SUPER CH 2-100 has been especially designed for the lubrication of roller bar chains and bending rods/pins in continuous wood presses of Messrs. Dieffenbacher and Siempelkamp.
- HOTEMP SUPER CH 2-100 dissolves and regenerates pasty oil residues and reduces or prevents chain contamination.
Application notes
- HOTEMP SUPER CH 2-100 is used in a separate lubrication circuit to lubricate the roller bar chains/pins.
- In addition, HOTEMP SUPER CH 2-100 can be used to lubricate all chains which require a low-viscous oil with good penetrating properties for cleaning purposes.
Technical specifications
| Chemical composition, type of oil | ester oil |
| Lower service temperature | 0 °C / 32 °F |
| Upper service temperature | 250 °C / 482 °F |
| Appearance | clear |
| Color space | yellow |
| Density, DIN 51757, 20 °C | approx. 0.92 g/cm³ |
| Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C | approx. 105 mm²/s |
| Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C | approx. 14.5 mm²/s |
| Flash point, DIN EN ISO 2592, Cleveland, open-cup apparatus | >= 250 °C |
| Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the unopened original container, approx. |
24 months |
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
