Description
STRUCTOVIS HD is a special lubricant series based on mineral oil and available in different viscosity grades
- The STRUCTOVIS types AHD to EHD, BHD MF and BHD 75 S contain special adhesion improvers, the type BHD MF the solid lubricant MoS2 for improved emergency lubricating properties
- STRUCTOVIS BHD 75 S contains a flammable solvent. All STRUCTOVIS HD types offer good wear and corrosion protection
- The STRUCTOVIS types provided with an adhesion improver are extremely adhesive thus reducing considerably the risk of contamination due to oil leakage, especially at high chain speeds
- The STRUCTOVIS types of higher viscosity (AHD to CHD) may also reduce noise of chains
- Content: 250ml aerosol can
Benefits
- Good wear protection
- Good corrosion protection
- Adhesive
- Noise dampening (depending on viscosity)
- Emergency lubricating properties (BHD MF)
Application
- STRUCTOVIS HD lubricants are used for driving, control and conveyor chains
- STRUCTOVIS BHD and BHD 75 S have proven particularly effective for the initial lubrication of steel link chains by the chain manufacturer
Technical specifications
| Article number | 16002 |
| Lower service temperature | -5 °C / 23 °F |
| Upper service temperature | 120 °C / 248 °F |
| Colour space | brown |
| Density, DIN 51757, 20 °C | approx. 0.91 g/ cm³ |
| Kinematic viscosity, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C | approx. 4 750 mm²/s |
| Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the unopened original container, approx. |
24 months |
Hazard Statements (CLP)
Signal word: Danger.
Hazard Statements (H-Sentences)
- H222: Extremely flammable aerosol.
- H229: Pressurized container: May burst if heated.
- H304: May be fatal if swallowed and enters airways.
- H315: Causes skin irritation.
- H412: Toxic to aquatic life with long-lasting effects.
Precautionary Statements (P-Sentences)
Prevention:
- P210: Keep away from heat, hot surfaces, sparks, open flames, and other ignition sources. No smoking.
- P211: Do not spray on an open flame or other ignition source.
- P251: Do not pierce or burn, even after use.
Response:
- P301 + P310: IF SWALLOWED: Immediately call a POISON CENTER/doctor.
- P331: Do not induce vomiting.
Storage:
- P410 + P412: Protect from sunlight and do not expose to temperatures exceeding 50 °C/122 °F.
Hazardous materials. The forwarding charges may be raised, if shipping to: DE, AT, NL, GB, CH, CZ, IT, ES, FI, NO, BE, IE, RO, PL, FR, PT, LU, DK, LI, GR, SE, SK, BG, SI, CA, LT, EE, LV, HR, SA,
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
