Description
- Service temperature range: -45°C to + 240°C
- high-quality brand of hightemperature lubricants based on perfluorinated polyether oil (PFPE)
- made using particularly fine PTFE thickeners and have an oil content that is unusually high for this type of grease
- Colour: white
- Size: 180g can
- also available as: can: 1kg
Benefits for your application
+ Long-term availability and service life of component
- over a wide service temperature range up to 260°C
- when exposed to aggressive chemical agents and vapours
- when using sensitive plastic materials
+ Tried and tested over many years in numerous industries and component types
- due to BARRIERTA base oils, which are made specifically to enable long-term stability
- backed by a large number of approvals and references
Application
- rolling and plain bearings operating at elevated temperature: long service lives when used in rolling and plain bearings operating under high thermal stress; smooth running of bearings also at high speeds and ensure a long life of the lubricated components; film stretchers, textile stenter frames, precision engineering, clean-room engineering (e.g. microchip manufacture)
- ultra-high vacuum application due to low vapour pressures
- electrical contacts: long-term lubrication of electrical contacts in high and medium-voltage switchboards
- widely neutral towards elastomers and plastics (possible exception: highly fluorinated rubber)
BARRIERTA is Europe’s oldest high-quality brand of high-temperature lubricants based on perfluorinated polyether oil (PFPE).
BARRIERTA products are among the most widely used PFPE lubricants today.
High-temperature greases of the BARRIERTA I series are made using particularly fine PTFE thickeners and have an oil content that is unusually high for this type of grease.
To suit various application purposes, BARRIERTA I greases are available in four different viscosities.
Technical Specifications
| Chemical composition, solid lubricant | PTFE |
| Chemical composition, type of oil | PFPE |
| Lower service temperature | -45 °C / -49 °F |
| Upper service temperature | 240 °C / 464 °F |
| Colour space | white |
| Density at 20 °C | approx. 1.95 g/cm³ |
| NLGI grade, DIN 51818 | 2 |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ ASTM D-445/ASTM D 7042, 40 °C | approx. 200 mm²/s |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ ASTM D-445/ASTM D 7042, 100 °C | approx. 22 mm²/s |
| Shear viscosity at 25 °C, shear rate 300 s-1, equipment: rotational viscometer, lower limit value | 4 000 mPas |
| Shear viscosity at 25°C, shear rate 300 s-1, equipment:rotational viscometer, upper limit value | 7 000 mPas |
| Corrosion inhibiting properties of lubricating greases, DIN 51802, (SKF-EMCOR), test duration: 1 week, distilled water |
<= 1 corrosion degree |
| Corrosion inhibiting properties of lubricating greases, DIN 51802, (SKF-EMCOR), test duration: 1 distilled water |
<= 1 corrosion degree |
| Flow pressure of lubricating greases, DIN 51805, test temperature: -40 °C | |
| Flow pressure of lubricating greases, DIN 51805, test temperature:-45 °C | <= 1 400 mbar |
| Flow pressure of lubricating greases, DIN 51805-2, test temperature: -50 °C | |
| Four-ball tester, welding load, DIN 51350 pt. 04 | approx. 5 000 N |
| Speed factor (n x dm) | approx. 600 000 mm/min |
| Minimum shelf life from the date of manufacture – in dry, frost-free place and in the unopened original container, approx. |
60 months |
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
