DELO-DUOPOX 6950 Universal 2-component epoxy resin adhesive 1 kg

Characteristics

• Compliant with RoHS Directive 2015/863/EU
• Long-term preheating of components is possible
• The filler may sediment. Therefore, the individual components must be stirred before use
• Any formation of bubbles during homogenization or mixing can be significantly minimized by using a processing system with vacuum unit
• Package size: Comp.A 665g can, Comp.B 335g can

Function

• Electronic encapsulant

Curing

• Curing time: 24 h

Processing

• Mixing ratio A : B – volume 17 : 10
• Mixing ratio A : B – weight 2 : 1
• Processing time after mixing (n 100 g batch at rt approx. +23 °C): 95 min
• Storage life in unopened original container (at +18 °C to +25 °C): 12 months

Technical properties

• Color in cured condition in 1 mm layer thickness: black
• Temperature range: -40 to +120 °C
• Density Component A | DELO Standard 13 | liquid: 1.16 g/cm³
• Density Component B | DELO Standard 13 | liquid: 0.95 g/cm³
• Viscosity Component A | liquid | Viscosimeter: 2100 mPa·s
• Viscosity Component B | liquid | Viscosimeter: 400 mPa·s
• Shore hardness D by the criteria of DIN EN ISO 868 | at approx. +23 °C | 7 d: 56
• Glass transition temperature DELO Standard 24 | Rheometer: 57 °C
• Dielectric strength by the criteria of DIN EN 60243-1: 26 kV/mm

Hazard Statements (CLP)

Signal word: Danger

Hazard Statements (H-Sentences)

• H314: Causes severe skin burns and eye damage.
• H315: Causes skin irritation.
• H317: May cause an allergic skin reaction.
• H319: Causes serious eye irritation.
• H400: Very toxic to aquatic life.
• H410: Very toxic to aquatic life with long-lasting effects.
• H411: Toxic to aquatic life with long-lasting effects.
• H412: Harmful to aquatic life with long-lasting effects.

DELO Industrie Klebstoffe GmbH & Co. KGaA, DELO-Allee 1, 86949 Windach, GERMANY, +49 8193 9900-0, [email protected], www.delo.de
