EMI Shielding Tape – WE-CF Series
WE-CF series self adhesive EMI shielding tape coated with aluminium or copper with a very high shielding effect. This is by virtue of its highly conductive adhesive with metal powder. Applications for the WE-CF series EMI Shielding Tape include EMI-Protection of doors and housings. The WE-CF series EMI Shielding Tape can also be used in conjunction with the WE-ST series conductive Ni/Cu woven glass fiber sleeve.
Operating Temperature Range : -25ºC to +85ºC
Approvals
UL-listed
EMI/RFI Shielding Tapes
When using these tapes galvanic compatibility should be taken into account.
Specifications
| Total Thickness | 0.07mm |
|---|---|
| Tape Type | Aluminium Tape |
| Foil Thickness | 0.035mm |
| Width | 25mm |
| Length | 33m |
| Conductivity | Conductive |
| Adhesion Strength | 5 N/cm |
| Adhesive Material | Acrylate |
| Tensile Strength | 14N/cm |
| Maximum Temperature Resistance | +85°C |
| Minimum Temperature Resistance | -25°C |
