Perma PRO LC500 Lubricant cartridge with Isoflex Topas NCA 52

Perma PRO LC500 Lubricant cartridge with Isoflex Topas NCA 52 | N° 106794

Isoflex Topas NCA 52 Synthetic long-term grease

• Reduced maintenance due to long-term or lifetime lubrication
• Reliable operation and many years of practical experience
• Wide application range even with high loads
• Low starting and running torques particularly at low temperatures ensure high efficiency and energy savings
• Longer component life due to good wear protection

Technical specifications

• Chemical composition, type of oil: synthetic hydrocarbon oil
• Chemical composition, thickener: special calcium soap
• Lower service temperature: -50 °C / -58 °F
• Upper service temperature: 130 °C / 266 °F
• Colour space: beige
• Density at 20 °C: approx. 0,89 g/cm³
• Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C: approx. 31 mm²/s
• Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C: approx. 5,9 mm²/s
• Drop point, DIN ISO 2176, IP 396: >= 220 °C

Applications

• ISOFLEX TOPAS NCA 52 is used for high-speed rolling and plain bearings as well as for small gears subject to high loads. Due to the good compatibility with plastics the grease is suitable for plastic-plastic or metal-plastic material combinations. The low starting torque and the good wear protection make it an ideal grease for the long-term lubrication of linear motion guides and ball screws, e.g. in handling and automation technology.
• ISOFLEX TOPAS NCA 52 can also be used for many automobile applications, e.g. for the lifetime lubrication of seat rails. It is suitable for components which have to be lubricated prior to dip painting and the drying process at peak temperatures of 180 °C as the lubricant remains at the friction point and provides reliable lubrication even after short thermal treatment.

---

Perma PRO ​Multi-Point Lubrication Systems:

PRO MP-6

• PRO MP-6 is a battery operated multi-point lubrication system.
• The MP-6 distributor discharges directly without pressure loss and enables tube extensions up to 5 m.
• PRO MP-6 is suitable for the lubrication of roller- and sliding bearings, linear guides, open gears, spindles, motor shaft seals, generators, pumps, fans and linear guide systems in robots.
• Applications can be found in all types of industries: from steel to paper, heat and power stations, from mining to automotive.
• Power supply: Battery PRO B

PRO C MP-6

• PRO C MP-6 can also be operated in IMPULSE mode.
• The impulse for a lubricant discharge can be PLC controlled.
• Power is supplied via the machine and can be PLC monitored and controlled.
• PRO C MP-6 is suitable for the lubrication of roller- and sliding bearings, linear guides, open gears, spindles, motor shaft seals, generators, pumps, fans and linear guide systems (with same size runner blocks) in robots.
• Applications can be found in all types of industries: from steel to paper, heat and power stations, from mining to automotive.
• Power supply: External: 15-30 V

PRO LINE

• PRO LINE is a special multi-point lubrication system for linear guides.
• Main applications for the multi-point lubrication system perma PRO LINE are linear guides.
• Application fields range from various linear guide and drive units in all kinds of industries – from automotive to paper. Other applications are roller and sliding bearings, open gears and spindles.
• Power supply: Battery PRO B

PRO C LINE

• PRO C LINE is a special multi-point lubrication system with 1 – 6 outlet connections for linear guides
• PRO C LINE receives its power from the machine and can be monitored and controlled via PLC.
• Main applications for the multi-point lubrication system perma PRO C LINE are linear guides.
• Application fields range from various linear guide systems and drives in the automotive industry to the paper industry. Other applications are roller and sliding bearings, open gears and spindles.
• Power supply: External: 15-30 V
