Perma PRO LC500 Lubricant cartridge with high-temp grease SF05

Perma PRO LC500 Lubricant cartridge with SF05 high-temperature grease | N° 106758

Perma High temp. / Extreme pressure grease SF05

• ​Multipurpose grease for extreme requirements
• High load-carrying capacity
• Good dry-running properties thanks to solid lubricants

Technical specifications

• Color: black
• NLGI-grade:  0/1
• Thickener: Polyurea + MoS2
• Base oil: Mineral oil + PAO
• Operating temperature: -20 to+160
• Viscosity at +40 °C [mm²/s]: 500
• Speed index: 200,000

Applications

• Roller bearings
• Sliding bearings
• Open gears / gear racks

---

​Perma PRO ​Multi-Point Lubrication Systems:​

PRO MP-6

• PRO MP-6 is a battery operated multi-point lubrication system.
• The MP-6 distributor discharges directly without pressure loss and enables tube extensions up to 5 m.
• PRO MP-6 is suitable for the lubrication of roller- and sliding bearings, linear guides, open gears, spindles, motor shaft seals, generators, pumps, fans and linear guide systems in robots.
• Applications can be found in all types of industries: from steel to paper, heat and power stations, from mining to automotive.
• Power supply: Battery PRO B

PRO C MP-6

• PRO C MP-6 can also be operated in IMPULSE mode.
• The impulse for a lubricant discharge can be PLC controlled.
• Power is supplied via the machine and can be PLC monitored and controlled.
• PRO C MP-6 is suitable for the lubrication of roller- and sliding bearings, linear guides, open gears, spindles, motor shaft seals, generators, pumps, fans and linear guide systems (with same size runner blocks) in robots.
• Applications can be found in all types of industries: from steel to paper, heat and power stations, from mining to automotive.
• Power supply: External: 15-30 V

PRO LINE

• PRO LINE is a special multi-point lubrication system for linear guides.
• Main applications for the multi-point lubrication system perma PRO LINE are linear guides.
• Application fields range from various linear guide and drive units in all kinds of industries – from automotive to paper. Other applications are roller and sliding bearings, open gears and spindles.
• Power supply: Battery PRO B

PRO C LINE

• PRO C LINE is a special multi-point lubrication system with 1 – 6 outlet connections for linear guides
• PRO C LINE receives its power from the machine and can be monitored and controlled via PLC.
• Main applications for the multi-point lubrication system perma PRO C LINE are linear guides.
• Application fields range from various linear guide systems and drives in the automotive industry to the paper industry. Other applications are roller and sliding bearings, open gears and spindles.
• Power supply: External: 15-30 V
