Perma FUTURA 120 Lubricant dispenser with food grade oil SO70

Perma FUTURA 120 Lubricant dispenser with SO70 | N° 107107

Perma Food grade oil H1 SO70

• NSF H1-registration
• Wide operating temperature range
• Excellent ageing and oxidation stability
• Good wear protection
• High scuffing load capacity
• Good corrosion protection
• Neutral towards seals and paints

Technical specifications

• Base oil: ester / PAO
• ISO VG DIN 51519: 220
• Cinematic viscosity, DIN 51561,
  • at 40°C, mm²/s: 220
  • at 100°C, mm²/s: 26
• Colour: colorless
• Density, DIN 51757, at 20 °C, g/cm3, approx.: 0.85
• Viscosity index, DIN ISO 2909: 150
• Pourpoint, DIN ISO 3016, °C: < -30
• Service temperature range, °C: – 30 to 120

Applications

• Perma Food grade oil H1 SO70 is used for the lubrication of friction points in food-processing and pharmaceutical machinery.
• It is especially suitable for the lubrication of spur, bevel and worm gears, bearings, spindles and joints, as well as of lift, drive and conveyor chains at low temperatures.

Perma FUTURA Lubricant dispenser

• Perma FUTURA is a single-point lubrication system for roller- and sliding bearings, sliding guides, open gears, gear racks, spindles, shaft seals, chains, etc.
• Operates at ambient temperatures between 0 up to +40 °C.
• Perma FUTURA has a corrosion-proof plastic housing which makes it ideal for hygienically clean applications (e. g. food and chemical industry).
• The reliable operating principle is based on an electrochemical reaction.
• The lubrication period is determined by color coded activator screws.
• Depending on your application’s requirement, you may choose to discharge 120 cm³ in a period of 1, 3, 6 or 12 months.
• The activator screw generates pressure (max. 4 bar) which moves the piston forward and continuously injects small lubricant amounts into the lubrication point
• Quick and easy exchange without special tools

Note: For each FUTURA dispenser you need an activator screw, which you can order under the links below:
