Perma FLEX M125 Lubricant dispenser with Klübersynth UH1 64-1302

Perma Flex M125 Lubricant dispenser with Klübersynth UH1 64-1302 | N° 115331

Klübersynth UH1 64-1302 Synthetic lubricating grease for the food and pharmaceutical industry

• Klübersynth UH1 64-1302 was specifically developed for grease-lubricated roller chains operating under high loads in the mixed friction regime in continuous flow sterilizers.
• Klübersynth UH1 64-1302 thus offers excellent wear protection even under extreme lubricating conditions.
• Being highly resistant to water and steam, this adhesive lubricating grease is particularly suitable for applications in a saturated steam atmosphere at normal sterilisation temperatures.
• For detailed information view our datasheet here

Technical specifications

• Colour: beige
• NLGI grade, DIN 51818: 2
• Chemical composition, type of oil synthetic: hydrocarbon oil
• Chemical composition, thickener: silicate
• Lower service temperature: -10 °C / 14 °F
• Upper service temperature: 140 °C / 284 °F
• Density at 20 °C approx.: 0.99 g/cm³
• Worked penetration, DIN ISO 2137, 25 °C, lower limit value: 265 x 0.1 mm
• Worked penetration, DIN ISO 2137, 25 °C, upper limit value: 295 x 0.1 mm

Applications

• Good adhesiveness, excellent protection against wear and strong resistance to steam and water make Klübersynth UH1 64-1302 ideal for the following applications: high-load lowspeed rolling and plain bearings, joints, toothed racks, tubular tracks, cams, stuffing boxes, high-load and grease-lubricated chains, etc.

---

Perma Flex M125 Lubricant dispenser

• The automatic lubrication system perma FLEX is available in two convenient sizes (60 cm³ / 125 cm³).
• It can be used for inside or outside applications at temperatures ranging from -20 °C to +60 °C.
• Discharge period setting is flexible and can be adjusted from 1 – 12 months using the dial on top of the lubricator.
• Perma FLEX comes fully assembled and ready-to-use. Simply turn the dial to the desired discharge period and the system is activated.
• The electronically controlled chemical reaction will build up the pressure that is necessary to continually supply the lubrication point with fresh lubricant.

Information on product safety (Manufacturer, Contact)

perma-tec GmbH & Co. KG, Hammelburger Str. 21, 97717 Euerdorf, Deutschland, +49 9704 609-0, [email protected]
