Perma CLASSIC 120 Single-point lubricator with multipurpose oil SO32

Perma CLASSIC 120 Lubricant dispenser with SO32 | N° 100449

Perma Multipurpose oil SO32

• High-performance gear and multipurpose oil
• Ageing and oxidation resistance
• FZG scuffing load stage >12
• High micro pitting resistance
• Good wear protection for gear teeth and rolling bearings
• Low foam generation

Technical specifications

• Base oil: mineral
• ISO VG DIN 51519: 100
• Kinematic viscosity, DIN 51561,
  • at 40 °C, mm²/s: 100
  • at 100 °C, mm²/s: 11
• Colour: yellow
• Density, DIN 51757, at 20 °C, g/cm3: approx. 0,85
• Viscosity index, DIN ISO 2909: 90
• Pourpoint, DIN ISO 3016, °C :< -15
• Service temperature range, °C: – 5 to 100

Applications

• Perma Multipurpose oil SO32 is suitable for lubrication of spur bevel and worm gears may also be
  used to lubricate plain and rolling bearings, spindles, chains, slide-ways, joints and gear couplings.

Perma CLASSIC 120 Automatic lubrication system

• Perma CLASSIC is a single-point lubrication system for roller- and sliding bearings, sliding guides, open gears, gear racks, spindles, shaft seals, chains, etc.
• Operates at ambient temperatures between 0 up to +40 °C.
• Typical applications can be found in mining, steel, automotive and mechanical engineering.
• The reliable operating principle is based on an electrochemical reaction.
• The lubrication period is determined by color coded activator screws.
• Depending on your application’s requirement, you may choose to discharge 120 cm³ in a period of 1, 3, 6 or 12 months.
• The activator screw generates pressure (max. 4 bar) which moves the piston forward and continuously injects small lubricant amounts into the lubrication point
• Perma CLASSIC is fully dust and water proof and can withstand impacts and accidental knocks.

Note: For each Classic 120 dispenser you need an activator screw, which you can order under the links below:
