Description
OKS 570 PTFE bonded coating for dry lubrication of different material pairs at low pressures, low speeds and in dusty environments
Field of application
- Dry lubrication of the most varied materials sliding on top of or rubbing against each other (such as metals, wood, ceramic, rubber, and also adhesives or paintable plastics)
- For packaging machines, sliding areas in the plastic and textile industry, rollers, and slides in transportation areas, etc.
- Anti-stick coating of seals or sealing surfaces of all kinds to prevent sticking-on
- To cure the squeaking noises of soft on hard materials
- For water-repellent impregnation of absorbent materials
- Separating film in cast resin applications
Properties
- Dry, non-soiling film
- Highly effective due to good adhesion to prepared substrates
- Colourless and odourless low-friction coating with non-stick properties
- Prevents frictional corrosion
- Dries at room temperature
Technical Data
- Manufacturer’s number: 00570031
- Composition: PTFE, silicone resin, gasoline, ketones, UV indicator
- Operating temperature: -180°C to +260°C
- Drying time at 20°C: 15 minutes
- Optimal layer thickness: 5 to 20 µm
- Processing temperature: Room temperature
- Density (20°C): 0.83 g/ml
- Color: Whitish
- Press-Fit Test: µ = 0.07
- Thread friction coefficient (M10/8.8): µ = 0.10
- Packaging: 500 ml can
- Also available in: 400 ml spray can (OKS 571), 5 kg bucket, 25 kg bucket, 180 kg drum
Applications notes
- For best adhesion, clean the surfaces.
- Best way is to clean mechanically first and then with OKS 2610 or OKS 2611 universal cleaner.
- The surfaces to be treated must be bright metal and dry.
- Chemical or mechanical pretreatment of surfaces may extend the service life of the non-stick paint.
- Stir the paint thoroughly before use.
- Apply in an evenly thin film to the prepared surfaces, preferably by spraying or dipping, in individual cases also by brush.
- Avoid local excess.
Industries
- Rail vehicle technology
- Municipal services
- Iron and steel industry
- Rubber and plastic processing
- Logistics
- Paper and packaging industry
- Chemical industry
- Shipbuilding and marine technology
- Plant and machine (tool) engineering
- Glass and foundry industry
Hazard Information (CLP)
Signal Word: Danger
Hazard Statements (H-phrases)
- H225: Highly flammable liquid and vapour.
- H304: May be fatal if swallowed and enters airways.
- H315: Causes skin irritation.
- H319: Causes serious eye irritation.
- H336: May cause drowsiness or dizziness.
- H411: Toxic to aquatic life with long lasting effects.
Precautionary Measures (P-phrases)
- P210: Keep away from heat, hot surfaces, sparks, open flames and other ignition sources. No smoking.
- P273: Avoid release to the environment.
Emergency Measures
- P301 + P310: IF SWALLOWED: Immediately call a POISON CENTER/ doctor.
- P331: Do NOT induce vomiting.
- P370 + P378: In case of fire: Use alcohol-resistant foam, carbon dioxide or water mist to extinguish.
- P391: Collect spillage.
Storage and Disposal
- P403 + P235: Store in a well-ventilated place. Keep cool.
Hazardous Components
- Hydrocarbons, C6-C7, n-alkanes, isoalkanes, cyclics, <5% n-hexane
- Butanone
- Acetone
- Xylene
Hazardous materials. The forwarding charges may be raised, if shipping to: DE, AT, NL, GB, CH, CZ, IT, ES, FI, NO, BE, IE, RO, PL, FR, PT, LU, DK, LI, GR, SE, SK, BG, SI, CA, LT, EE, LV, HR, SA,
OKS Spezialschmierstoffe GmbH, Ganghoferstr. 47, D-82216 Maisach-Gernlinden, +49 8142 3051 500, [email protected], www.oks-germany.com
