Description
Motorex GEAR COMPOUND PLUS 220 is a mineral-based high performance gear oil (CLP, ISO VG 220). At high, abrupt loads, a protective oil film always remains between the force-transmitting surfaces.
Application
- The oil is recommended for use in a number of spur gears, bevel gears and planetary gears produced by well-known manufacturers.
- The remarkable quality of this lubricant is particularly apparent when used under difficult conditions.
- It is therefore perfect for industrial gears used in gravel plants, mountain railways, industrial plants and sewage-treatment plants.
Specifications & Approvals
- ISO 12925-1
- ISO 6743-6 L-CKB
- ISO 6743-6 L-CKC
- DIN 51517-3 CLP
- AGMA 9005/E02
- AIST 224 (U.S. STEEL)
- SEB 181226
- FLENDER, REV.14
Characteristics
- Excellent corrosion protection
- High level of wear protection
- High micro-pitting resistance
- Compatible with the majority of seal materials used
- Very good demulsifying properties
- Low foaming tendency
- Excellent shear stability
- High ageing and oxidation stability
- Volume: 5 l canister
- Also available in: 1 l canister, 20 l canister, 25 l canister, 12 X 1 l carton, 60 l drum, 200 l barrel
Technical specifications
| Manufacturer number | 301083 | ||
| Colour | brown | ||
| Density at 20 °C | g/cm³ | ASTM D4052 | 0.895 |
| Viscosity at 40 °C | mm²/s | DIN 51562-1 | 220 |
| Viscosity at 100 °C | mm²/s | DIN 51562-1 | 18.9 |
| Viscosity index | DIN ISO 2909 | 96 | |
| Pourpoint | °C | ASTM D5950 | -24 |
| Flash point C.O.C. | °C | DIN EN ISO 2592 | >200 |
| Demulsifying capability / 54°C | min. | DIN 51599 | >60 |
| FZG – test | DIN 51354-2 | >12 | |
| micro pitting endurance test | FVA-54/II | GFT hoch | |
| micro pitting stage test | FVA-54/II | GFT hoch | |
| Copper corrosion | DIN EN ISO 2160 | 1 | |
| Steel corrosion | DIN ISO 7120 DIN 51585 | 0 | |
| TAN NZ | mg KOH/g | ASTM D 664-95 DIN 51558-1 | 0.3 |
MOTOREX AG, Bern-Zürich-Strasse 31, 4901 Langenthal, SWITZERLAND, +41 62 919 75 75, [email protected], www.motorex.com
