Description
Extremely pure, solid lubricant paste for bolted joints. It contains no lead, nickel, sulphur, chlorine or fluorine
Highlights
- Highly pure (less than 500mg of sulphur, less than 200mg of chlorine and fluorine per kg of lubricant)
- Can be used at temperatures up to 1400°C (2552°F)
- Coefficient of friction in the range of oiled bolts
- Low scatter of prestressing force on tightening
- Avoidance of stress cracks and solder brittleness
- Enables non-destructive loosening of bolted joints even after long use at high temperatures
- Complies with Siemens TLV 9600 02/01
- Complies with General Electric TIL 1117-3RI
- Complies with EDF-PMUC 04034 Complies with Pratt & Whitney PWA-36246
Application
- Suitable for screws, nuts and bolts that are subjected to extremely high temperatures and which are made of heat-resistant or extremely heat resistant steels, eg those made from nickel-based alloys
- Used successfully for the bolted joints of gas and steam turbines in power stations
Technical specifications
| Composition | Solid lubricants in practically sulphur free, partly, synthetic oil Thickener Adhesion improver |
| Physical form | curing compound |
| Color | Grey-black |
| Penetration unworked (ISO 2137) | 280 to 310 mm/10 |
| Weld load (DIN 51 350 T.4) | 4400 N |
| Wear scar under 800N load (DIN 51 350 T.5) | 1.7 mm |
| Screw test – µ thread | 0.15 |
| Screw test – µ head | 0.09 |
| Initial break-away torque | 126 Nm |
| Density at 20°C (68°F) (ISO 2811) | 1.2 g/mol |
| Usage temperature range | -40 °C to 1400 °C (2552 °F) |
Hazards Information (CLP)
Signal Word: DANGER.
Hazard Statements (H-phrases)
- H315: Causes skin irritation.
- H318: Causes serious eye damage.
Precautionary Statements (P-phrases)
Prevention:
- P264: Wash skin thoroughly after handling.
- P280: Wear protective gloves/ eye protection/ face protection.
Response:
- P302 + P352: IF ON SKIN: Wash with plenty of water.
- P305 + P351 + P338 + P310: IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing. Immediately call a POISON CENTER/doctor.
- P332 + P313: If skin irritation occurs: Get medical advice/attention.
- P362 + P364: Take off contaminated clothing and wash it before reuse.
Additional Information
- The following percentage of the mixture consists of ingredient(s) of unknown acute dermal toxicity: 29%.
DuPont de Nemours (Deutschland) GmbH, Hugenottenallee 175, 63263 NEU-ISENBURG, GERMANY, +49 (0) 6102 18 – 0, [email protected], www.dupont.de
