Mobil SHC 524 Synthetic hydraulic oil ISO VG 32, 20L canister

Exxon Mobil SHC™ 524 is a fully synthetic hydraulic oil (ISO VG 32) with exceptional performance for wide temperature use (DENISON HF-0, HF-1, HF-2 approved).

Application

• Hydraulic systems prone to deposit build-up such as sophisticated Numerically Controlled (NC) machines, particularly where close clearance servo-valves are used
• Systems employing multi-metal component designs
• High pressure vane, piston and gear pumps
• Systems where cold start-up and / or very high operating temperatures are typical
• Where small amounts of water are unavoidable
• In systems containing gears and bearings
• Systems requiring a high degree of load-carrying capability and anti-wear protection
• Applications where thin oil-film corrosion protection is an asset such as in systems containing moisture

Approvals

• DENISON HF-0
• DENISON HF-1
• DENISON HF-2

Specifications & Approvals

• Design-Specific synthetic base stock
• Exceptional anti-wear
• High viscosity index
• Outstanding oxidation stability
• Excellent corrosion protection
• Very good multi-metal compatibility
• Meets a wide range of equipment requirements
• Excellent air separation characteristics
• Controlled demulsibility
• Innovative keep clean properties
• Size: 20l canister
• Also available in: 208l barrel

Advantages and Potential Benefits

• Helps extend service intervals
• Cleaner system and reduced close-tolerance valve sticking compared to conventional products
• Helps improve filterability
• Helps reduce wear of components
• Helps protect systems using various metallurgy
• Wide temperature range performance
• Helps to ensure equipment protection at cold start-up temperatures
• Helps protect system components at high operating temperatures
• Helps provide long oil and equipment life, which can extend filter life
• Helps prevent internal hydraulic system corrosion
• Helps reduce the negative effects of moisture in systems
• Helps provide corrosion protection of multi-metallurgy component designs
• Helps optimize inventory requirements
• One product can replace several helping to optimize inventory requirements and mitigate potential product misapplication
• Helps reduce foaming and it’s negative effects
• Provides systems protection and lubrication where small quantities of moisture are present
• Readily separates larger quantities of water
• Helps reduce system deposits and potential sludging
• Helps protect critical components such as servo-valves, improving system response and minimizing valve sticking

Technical specifications

Manufacture number	127659
Grade	ISO 32
Brookfield Viscosity @ -18 C, mPa.s, ASTM D2983	923
Copper Strip Corrosion, 3 h, 100 C, Rating, ASTM D130	1B
Density @ 15 C, kg/l, ASTM D4052	0.853
Emulsion, Time to 40/37/3, 54 C, min, ASTM D1401	20
FZG Scuffing, Fail Stage, DIN 51354	9
Flash Point, Cleveland Open Cup, °C, ASTM D92	234
Kinematic Viscosity @ 100 C, mm2/s, ASTM D445	6.4
Kinematic Viscosity @ 40 C, mm2/s, ASTM D445	32
Pour Point, °C, ASTM D97	-56
Rust Characteristics, Procedure B, ASTM D665	PASS
Viscosity Index, ASTM D2270	144

Product Description

Mobil SHC™ 500 Series oils are exceptional performance hydraulic oils formulated from synthesised, wax-free hydrocarbon base fluids combined with a carefully engineered super-stabilised additive system. They are exceptionally high quality, wide-temperature, shear-stable hydraulic oils with controlled low-temperature pumpability properties and maximised anti-wear protection for high-pressure vane, piston and gear pumps. The products exhibit very high viscosity indexes contributing to their excellent low and high temperature performance making them an excellent choice for equipment that is subjected to a wide range of start-up and operating temperatures. The Mobil SHC 500 Series oils exhibit outstanding shear stability allowing their use in high-pressure, high-temperature operating environments for extended periods of time without the loss of critical lubrication characteristics.

The Mobil SHC 500 Series oils help provide long oil/filter life and optimum equipment protection, which can reduce both maintenance and product disposal costs. They were developed in conjunction with the major OEMs to meet the stringent requirements of severe hydraulic systems using high pressure, high output pumps as well as handling the critical requirements of other hydraulic system components such as close clearance servo-valves and the high accuracy numerically controlled (NC) machine tools. These products meet some of the most rigorous performance requirements of a wide range of hydraulic system and component manufacturers, using various multi-metallurgy designs, ensuring a single product with exceptional performance characteristics in a wide range of equipment. They are designed to work with systems operating under severe conditions where high levels of anti-wear and film strength protection are needed, yet they are formulated to work where non-anti-wear hydraulic oils are generally recommended.

Information on product safety (Manufacturer, Contact)

EXXONMOBIL CENTRAL EUROPE HOLDING GMBH, Ericusspitze 2, 20457 Hamburg, GERMANY, +49 40 6393 0, [email protected], www.exxonmobil.de
