Description
Mobil HyJet™ V is a fire-resistant Type V phosphate ester hydraulic fluid designed for modern commercial aircraft systems. It offers significantly higher thermal and hydrolytic stability compared to Type IV fluids, extending service life and reducing maintenance requirements.
- Pack size: 946 ml can (1 U.S. Quart)
Applications
- Hydraulic systems in commercial aircraft using phosphate ester fluids
- Fully compatible with approved Type IV and Type V fluids
- Approved for use in Airbus, Boeing, Gulfstream and more
Features
- High flash point: 174 °C (fire point: 186 °C)
- Auto-ignition temperature >427 °F
- Excellent low temperature fluidity (pour point -80 °F)
- Very high viscosity stability (Viscosity Index: 280)
- Low shear loss (21 % after ASTM D5621)
Approvals and Specifications
- Airbus: NSA 307110N (Type V)
- Boeing: BMS 3-11P, Grade A & C
- Boeing Long Beach: DMS2014H, Type 5
- Gulfstream: 1159SCH302J, Type V
Typical Technical Data
| Kinematic viscosity @ 100 °F | 10.6 mm²/s (ASTM D445) |
| Kinematic viscosity @ 210 °F | 3.6 mm²/s (ASTM D445) |
| Kinematic viscosity @ -15 °F | 132 mm²/s (ASTM D445) |
| Pour point | -80 °F |
| Flash point (COC) | 174 °C (ASTM D92) |
| Fire point | 186 °C (ASTM D92) |
| Auto-ignition temp. | >427 °F (ASTM D2155) |
| Viscosity index | 280 |
| Shear loss | 21 % (ASTM D5621) |
| Total acid number | 0.04 mgKOH/g (ASTM D974) |
| Density @ 25 °C | 0.997 g/cm³ (ASTM D4052) |
| Potassium content | 4 ppm (ICPES) |
| Chlorine content | 10 ppm (IPS/004) |
| Sulfur content | 51 ppm (ICPES/XRF) |
Note: Mobil HyJet™ V is miscible with Type IV fluids, but any changeover must follow OEM recommendations.
Hazard Information (CLP)
Signal word: Warning
Hazard statements (H-phrases)
- H302: Harmful if swallowed.
- H319: Causes serious eye irritation.
- H351: Suspected of causing cancer.
- H361fd: Suspected of damaging fertility. Suspected of damaging the unborn child.
- H373: May cause damage to organs through prolonged or repeated exposure (adrenal glands).
- H410: Very toxic to aquatic life with long lasting effects.
Safety advice (P-statements)
Prevention:
- P201: Obtain special instructions before use.
- P202: Do not handle until all safety precautions have been read and understood.
- P260: Do not breathe vapour.
- P264: Wash thoroughly after handling.
- P270: Do not eat, drink or smoke when using this product.
- P273: Avoid release to the environment.
- P280: Wear protective gloves/protective clothing/eye protection/face protection/hearing protection.
Response:
- P301+P330+P312: IF SWALLOWED: Rinse mouth. Call a POISON CENTER/doctor if you feel unwell.
- P305+P351+P338: IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses if present and easy to do. Continue rinsing.
- P308+P313: If exposed or concerned: Get medical advice/attention.
- P337+P313: If eye irritation persists: Get medical advice/attention.
- P391: Collect spillage.
Storage:
- P405: Store locked up.
Disposal:
- P501: Dispose of contents/container in accordance with local, regional, national and international regulations.
Other relevant information
- Contains: tributyl phosphate and phenol, isopropylated, phosphate (3:1) [triphenyl phosphate > 5 %]
EXXONMOBIL CENTRAL EUROPE HOLDING GMBH, Ericusspitze 2, 20457 Hamburg, GERMANY, +49 40 6393 0, [email protected], www.exxonmobil.de
