Description
Product Details
MG Chemical potting compound
The MG Chemical potting compound is a general purpose, water clear, hard, two-part epoxy that offers extreme environmental, mechanical and physical protection for printed circuit boards and electronic assemblies. It does not yellow when exposed to UV light or elevated temperatures. This potting compound provides excellent electrical insulation and protects the circuit board and other electronic devices from static discharges, vibration, abrasion, thermal shock, environmental humidity, salt water, fungus, and many harsh chemicals. It has a convenient 2:1 volume mix ratio, making it compatible with most dispensing equipment.
Features and Benefits
• Convenient 2A:1B volume mix ratio
• Excellent electrical insulating characteristics
• Extreme resistance to water and humidity (allows for submersion where needed)
• Extremely high compressive and tensile strength
• Good adhesion to a wide variety of substrates including metals, composites, glass, ceramics, and many plastics
• Operating temperature ranges between -40°C and 140°C
• Optically clear colour (allows visual inspection)
• Package size 3L
• Solvent free
• Very low mixed viscosity of 980 cP
• Excellent electrical insulating characteristics
• Extreme resistance to water and humidity (allows for submersion where needed)
• Extremely high compressive and tensile strength
• Good adhesion to a wide variety of substrates including metals, composites, glass, ceramics, and many plastics
• Operating temperature ranges between -40°C and 140°C
• Optically clear colour (allows visual inspection)
• Package size 3L
• Solvent free
• Very low mixed viscosity of 980 cP
Applications
• Power supplies
• Switches
• Ignition coils
• Electronic modules
• Motors
• Connectors
• Sensors
• Cable harness assemblies
• Switches
• Ignition coils
• Electronic modules
• Motors
• Connectors
• Sensors
• Cable harness assemblies
Specifications
| Product Material | Epoxy |
|---|---|
| Package Type | Can |
| Package Size | 3 L |
| Cure Time | 1 h @ 80 °C, 2 h @ +65 °C, 30 min @ +100 °C, 72 h @ +22 °C |
| Colour | Transparent |
| Maximum Operating Temperature | +140°C |
| Minimum Operating Temperature | -40°C |
| Dielectric Strength | 18kV/mm |
| Viscosity Measurement | 980cP/s |
| Specific Gravity | 1.1 |
| Viscosity Description | Low |
| Operating Temperature Range | -40 → +140 °C |
| Physical Form | Liquid |
| Volume Resistivity | 1.6 x 10 ^ 17Ω cm |
