Description
The lubricator LUBCON MicroMax 120 is an economical solution for automatic long term lubrication. The self-sustaining electro-mechanical lubricator enables the lubrication of components in extreme operating conditions over long periods, even in areas which are hard to access.
Economical
- Easy installation and activation
- Automatic lubricant supply 24/7
- Optimum metering of the lubricant
- Combination of premium lubricant and intelligent lubrication device
- Battery driven, no external power needed
Robust and reliable
- Closed metal housing
- Completely sealed unit
- Performs in extreme environmental conditions (dust, water, heat)
- Installation in any position
Lubrication over long periods
- Individually adjustable operating time
- Possible operating range up to 36 months
- Lubrication device for minimum quantities e. g. at 3 years operating time: 40 cm3 per year
The MicroMax 120 is an electro-mechanical lubricator for automatic lubrication with grease or oil. The aluminium body of the MicroMax 120 contains 120 cm³ of lubricant. A linear progressive piston pushes the lubricant through the outlet to the lubrication point. The forward motion of the piston is generated by a geared motor and a spindle drive. The control of this motion as well as the activation and control of the gear motor is governed by a micro processor. A fixed, non-removable lithium battery supplies the electronic circuit and motor with power. The maximum operating time of the MicroMax 120 is three years.
Duration: 18 months
Lubricant: Grease Grizzly No. 1
We recommend a maximum storage 6 months
Lubricant Consult GmbH, Gutenbergstraße 13, 63477 MAINTAL (GERMANY), +49 6109/7650-0, [email protected], www.lubcon.com
