Description
Product Details
Loctite Thread lock
The Loctite 6300 is a green, fluorescent dimethacrylate ester acrylic adhesive designed for bonding cylindrical fitting parts. The product cures when confined in the absence of air between close-fitting metal surfaces and prevents loosening and leakage from shock and vibration. Typical applications include holding gears and sprockets onto gearbox shafts and rotors on electric motor shafts. There are no risk or safety warnings associated with formulation nor or its ingredients.
Note:
This product is not recommended for use in pure oxygen and/or oxygen rich systems and should not be selected as a sealant for chlorine or other strong oxidizing materials.
Note:
This product is not recommended for use in pure oxygen and/or oxygen rich systems and should not be selected as a sealant for chlorine or other strong oxidizing materials.
Features and Benefits
Absence of air between close-fitting metal surfaces cures the product
High-strength, high temperature resistance
Fluorescent
Prevents leakage and loosening from shock and vibration
Designed for the bonding of cylindrical fitting parts
Part of the Health and Safety anaerobic range
Compressive Shear Strength > 15 N/mm²
Cure time is 24 hours
Low viscosity of 200 → 550mPa/s
Operating temperature ranges between -55⁰C and 175⁰C
Applications
Holding gears
Sprockets onto gearbox shafts
Rotors on electric motor shafts
Certifications
ANSI/ESD S 20.20: 2014
BS EN 61340-5-1: 2007
BS EN 61340-5-1: 2007
Specifications
| Trade Name | Loctite 6300 |
|---|---|
| Application | Retaining |
| Material Compatibility | Metal |
| Colour | Green |
| Product Form | Liquid |
| Package Type | Bottle |
| Package Size | 50 ml |
| Cure Time | 24 h |
| Viscosity Measurement | 200 → 550mPa/s |
| Viscosity Description | Low Viscosity |
| Maximum Operating Temperature | +175°C |
| Special Features | Anaerobic |
| Odour | Characteristic |
| Operating Temperature Range | -55 → +175 °C |
| Minimum Operating Temperature | -55°C |
| Chemical Composition | Dimethacrylate Ester |
