Description
LOCTITE® HY 4070 Universal Bonder is designed for the assembly of parts with bond gaps up to 0.2 in (5 mm), and/or for applications where the complete cure of excess adhesive is a must. The gel consistency prevents adhesive flow even on vertical surfaces.
- Pack size: 11 g dual cartridge (Loctite no. 2237457)
Application
- Excellent bonding characteristics to a variety of substrates including plastics, rubbers, and metals
- HY 4070 is ideally suited for applications where temperature and moisture resistance is required
Characteristics
- Fast fixturing
- Moisture resistant
- Temperature resistance from -40 to +100°C
- Gap filling up to 5 mm
- Gel consistency prevents adhesive flow, even on vertical surfaces.
Technical specifications
| Application Method | Dispense System |
| Cure Type | Room Temperature (Ambient) Cure, |
| FEA (Finite Element Analysis) | Viscoelastic |
| Fixture Time, Aluminium (etched) 0.5mm gap | <60.0 sec. |
| Gap Fill | 5.0 mm |
| Mix Ratio, by Volume | 10 : 1 |
| Physical Form | Gel |
| Shear Strength, Steel (grit blasted) | 25.0 N/mm² (3625.0 psi ) |
| Technology | Hybrid Chemistry |
Loctite HY4070, Loctite HY-4070
Hazard Statements (CLP)
Signal Word: Warning
Hazard Statements (H-phrases)
- H315: Causes skin irritation.
- H319: Causes serious eye irritation.
- H335: May cause respiratory irritation.
Precautionary Statements (P-phrases)
- P261: Avoid breathing vapors.
- P280: Wear protective gloves/eye protection.
Response
- P337+P313: If eye irritation persists: Get medical advice/attention.
- P305+P351+P338: IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing.
Disposal
- P501: Dispose of contents/container in accordance with national regulation.
Supplemental Information
- Cyanoacrylate. Danger. Bonds skin and eyes in seconds. Keep out of the reach of children.
Hazardous materials. The forwarding charges may be raised, if shipping to: DE, AT, NL, GB, CH, CZ, IT, ES, FI, NO, BE, IE, RO, PL, FR, PT, LU, DK, LI, GR, SE, SK, BG, SI, CA, LT, EE, LV, HR, SA,
Henkel AG & Co. KGaA, Henkelstr. 67, 40589 Düsseldorf, GERMANY, +49 211 7970, [email protected], www.henkel.com
