Description
Synthetic lubricating grease for the food-processing and pharmaceutical industries (NSF H1 registered)
- Klübersynth UH1 64-1302 was specifically developed for grease-lubricated roller chains operating under high loads in the mixed friction regime in continuous flow sterilizers. Klübersynth UH1 64-1302 thus offers excellent wear protection even under extreme lubricating conditions
- Being highly resistant to water and steam, this adhesive lubricating grease is particularly suitable for applications in a saturated steam atmosphere at normal sterilisation temperatures.
- Klübersynth UH1 64-1302 is NSF H1 registered and therefore complies with FDA 21 CFR § 178.3570. The lubricant was developed for incidental contact with products and packaging materials in the food-processing, cosmetics, pharmaceutical or animal feed industries. The use of Klübersynth UH1 64-1302 can contribute to increase reliability of your production processes. We nevertheless recommend conducting an additional risk analysis, e.g. HACCP.
- Container size: 1kg can
- Also available in 400g cartridge, 1kg can, 25kg bucket, 50kg bucket
Benefits for your application
- Higher component availability and longer maintenance intervals, due to
- Good wear protection
- Good stability also at high temperatures
- Good resistance to water and steam
- Certified acc. to ISO 21469 – supports the compliance with the hygienic requirements in your production
Application
- Good adhesiveness, excellent protection against wear and strong resistance to steam and water make Klübersynth UH1 64-1302 ideal for the following applications: high-load lowspeed rolling and plain bearings, joints, toothed racks, tubular tracks, cams, stuffing boxes, high-load and grease-lubricated chains, etc.
Application notes
- Klübersynth UH1 64-1302 is applied by brush, spatula, grease gun, or centralised lubrication systems designed for NLGI 3 greases
Technical specifications
| Article number | 096049 |
| NSF-H1 registration | 136 697 |
| NLGI grade, DIN 51818 | 2 |
| Chemical composition, type of oil | synthetic hydrocarbon oil |
| Chemical composition, thickener | silicate |
| Lower service temperature | -10 °C / 14 °F |
| Upper service temperature | 140 °C / 284 °F |
| Color space | beige |
| Texture | homogeneous, fibrous |
| Density at 20 °C | approx. 0.99 g/cm³ |
| Worked penetration, DIN ISO 2137, 25 °C, lower limit value | 265 x 0.1 mm |
| Worked penetration, DIN ISO 2137, 25 °C, upper limit value | 295 x 0.1 mm |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C | approx. 100 mm²/s |
| Shear viscosity at 25 °C, shear rate 300 s-1; equipment:rotational viscometer | 15.000-20.000 mPas |
| Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the unopened original container, approx. |
24 months |
| 2 |
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
