Description
Klübersynth UH1 14-222 Synthetic lubricating grease for universal application in the food-processing and pharmaceutical industries | N° 096071
- Klübersynth UH1 14-222 was developed for the special requirements of the food-processing and pharmaceutical.
- Klübersynth UH1 14-222 is NSF H1 registered and therefore complies with FDA 21 CFR § 178.3570.
- The lubricant was developed for incidental contact with products and packaging materials in the food processing, cosmetics, pharmaceutical or animal feed industries.
- The use of Klübersynth UH1 14-222 can contribute to increase reliability of your production processes. We nevertheless recommend conducting an additional risk analysis, e.g. HACCP
- Temperature range: -25°C to +120°C
- Volume: 1kg can
- Also available in: 400g cartridge, 25kg bucket, 180kg drum
Benefits for your application
- Facilitates product streamlining owing to its wide range of applications
- Offers improved surface protection through good adhesion and its particular consistency
- ISO 21469 certified – supports the compliance with the hygienic requirements in your production. You will find further information about ISO Standard 21469 on our website www.klueber.com
Applications
- Klübersynth UH1 14-222 is suitable for use in machines, installations and equipment of the food-processing and pharmaceutical industries, particularly for lubrication points that
may have incidental and technically unavoidable contact with the food product. - This food-grade lubricant is intended for the universal lubrication of rolling and plain bearings, lifting cylinders, joints, guide rods and rails, cams, etc.
Technical specifications
| Article number | 096071 |
| NLGI grade, DIN 51818 | 2 |
| NSF-H1 registration | 128 827 |
| Lower service temperature | -25 °C / -13 °F |
| Upper service temperature | 120 °C / 248 °F |
| Colour space | beige |
| Texture | homogeneous |
| Density at 20 °C | approx. 0,94 g/cm³ |
| Worked penetration, DIN ISO 2137, 25 °C, lower limit value | 265 x 0,1 mm |
| Worked penetration, DIN ISO 2137, 25 °C, upper limit value | 295 x 0,1 mm |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C | approx. 260 mm²/s |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C | approx.29 mm²/s |
| Shear viscosity at 25 °C, shear rate 300 s-1, equipment: rotational viscometer, lower limit value | 6 000 mPas |
| Shear viscosity at 25°C, shear rate 300 s-1, equipment:rotational viscometer, upper limit value | 12 000 mPas |
| Low-temperature torque, IP 186, – 25 °C, start | <= 1 000 mNm |
| Low-temperature torque, IP 186, – 25 °C, running | <= 100 mNm |
| Drop point, DIN ISO 2176, IP 396 | >= 220 °C |
| Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the unopened original container, approx. | 24 months |
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
