Description
Klübersynth PEG 46-121 Special grease for the lubrication of enclosed gear drives | N° 027041
- Synthetic polyglycol oil based special grease with NLGI grade 1
- Temperature range: -50°C to +120°C
- Volume: 1kg can
- Also available in: 25kg bucket, 180kg drum
Benefits for your application
- The good wear protection of both the gears and the rolling bearings ensures a long service life of the components
- The excellent viscosity-temperature behaviour supports the formation of a sufficient lubricating film even at elevated and high temperatures
- Much longer service life than mineral oils due the excellent ageing und oxidation stability of the synthetic base oil used in Klübersynth PEG 46 greases: Thus maintenance intervals can be extended and in certain cases even lifetime lubrication is possible
- The excellent friction behaviour of the polyglycol base oil reduces power losses and improves efficiency
Applications
- Klübersynth PEG 46 greases were developed especially for the lubrication of spur gears, bevel gears, planetary gears and worm gears with material pairings steel/steel or steel/brass in small enclosed gear drives.
- Klübersynth PEG 46 greases can also be used for the lubrication of ball and roller guides, rolling and plain bearings as well as toothed couplings.
Application notes
- Immersion lubrication of gears operating at circumferential speeds up to approx. 10 m/s is possible if NLGI grade 00 is used. Sufficient heat dissipation is essential. Depending on the operating conditions higher circumferential speeds are possible. The dynamic stresses of design elements made of aluminium or aluminium alloys may lead to increased wear. If necessary, wear tests should be carried out.
Technical specifications
| NLGI grade, DIN 51818 | 1 |
| Lower service temperature | -50 °C / -58 °F |
| Upper service temperature | 120 °C / 248 °F |
| Colour space | brown |
| Texture | homogeneous |
| Density at 20 °C | approx. 0.98 g/cm³ |
| Worked penetration, DIN ISO 2137, 25 °C, upper limit value | 340 x 0.1 mm |
| Worked penetration, DIN ISO 2137, 25 °C, lower limit value | 310 x 0.1 mm |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C |
approx. 120 mm²/s |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C |
approx. 20 mm²/s |
| Drop point, DIN ISO 2176, IP 396 | >= 180 °C |
Hazard Information (CLP)
Signal word: Warning.
Hazard Statements (H-phrases)
- H317: May cause an allergic skin reaction.
Precautionary Statements (P-phrases)
Prevention:
- P272: Contaminated work clothing should not be allowed out of the workplace.
- P280: Wear protective gloves.
Response:
- P302 + P352: IF ON SKIN: Wash with plenty of water and soap.
- P333 + P313: If skin irritation or rash occurs: Get medical advice/attention.
- P362 + P364: Take off contaminated clothing and wash it before reuse.
Hazardous Components for Labeling
- Molybdenum trioxide, reaction products with Bis [O,O-bis(2-ethylhexyl)] hydrogen dithiophosphate
- Condensation products of fatty acids, tall oil with 2-amino-2-ethylpropanediol
KLÜBER LUBRICATION MÜNCHEN GMBH & CO. KG, Geisenhausenerstraße 7, 81379 München, GERMANY, +49 89 7876 0, [email protected], www.klueber.com
