Description
Klübersynth GHE 6-100 Synthetic gear and circulating oil (ISO VG 100) | N° 012278
- Klübersynth GHE 6 oils are polyglycol-based gear and circulating oils particularly resistant to ageing and oxidation offering high scuffing load capacity.
- Owing to their polyglycol base oil, Klübersynth GHE 6 oils have a good viscosity-temperature and excellent high-temperature behaviour.
- Temperature range: -35°C to +160°C
- Size: 20 canister
- Also available in: Canister 5 l, Drum 200 l
Benefits for your application
- Klübersynth GHE 6 oils offer much longer service life than mineral oils due to the excellent ageing and oxidation resistance of the synthetic base oil; thus maintenance intervals can be extended and in certain cases even lifetime lubrication is possible.
- Its high scuffing load resistance offers good scuffing protection even at high peak loads.
- The good wear protection of both gears and rolling bearings prevents premature component failure, leading to lower maintenance and repair costs.
- The optimum friction behaviour of the polyglycol base oil reduces power losses and improves efficiency.
- The excellent viscosity-temperature behaviour supports the formation of a separating lubricating film even at elevated temperatures.
- Seals made of 72 NBR 902, 75 FKM 585 and 75 FKM 170055 are resistant to Klübersynth GHE 6 oils. Leakage and contamination are prevented.
- Approved by Flottweg Separation Technology
Applications
- Klübersynth GHE 6 oils were specially developed for the lubrication of spur, bevel, planetary and worm gears.
- Klübersynth GHE 6 oils are also used for the lubrication of rolling and plain bearings as well as all kinds of toothed couplings
Application notes
- Klübersynth GHE 6 oils can be applied by immersion, immersion/circulation and injection.
- Klübersynth GHE 6 oils are not miscible with mineral oils and synthetic hydrocarbons. Prior to switchover, lubrication points should be cleaned, or gears or enclosed systems be flushed with Klübersynth GHE 6.
- Klübersynth GHE 6 oils are neutral towards virtually all nonferrous metals.
Technical specifications
| Article number | 0122780766 |
| Service temperature, lower limit | -35 °C |
| Service temperature, upper limit | 160 °C |
| Density, DIN 51757, 15°C | 1043 kg/m³ |
| Flash point, DIN EN ISO 2592, Cleveland open cup | ≥ 250 °C |
| Foam test, ISO 6247 / ASTM D892, 24°C, sequence I | ≤ 100/10 ml |
| Foam test, ISO 6247 / ASTM D892, 24°C, sequence III | ≤ 100/10 ml |
| Foam test, ISO 6247 / ASTM D892, 93.5°C, sequence II | ≤ 100/10 ml |
| ISO viscosity grade, DIN ISO 3448 | ISO VG 100 |
| Kinematic viscosity, DIN EN ISO 3104 / DIN 53000-1, based on standard / ASTM D445 / ASTM D7042, 100°C | approx. 20 mm²/s |
| Kinematic viscosity, DIN EN ISO 3104 / DIN 53000-1, based on standard / ASTM D445 / ASTM D7042, 20°C | approx. 270 mm²/s |
| Kinematic viscosity, DIN EN ISO 3104 / DIN 53000-1, based on standard / ASTM D445 / ASTM D7042, 40°C | approx. 100 mm²/s |
| Viscosity index, DIN ISO 2909 | ≥ 190 |
| Copper corrosion, DIN EN ISO 2160, 24 h, 100°C | 1 – 100 – 24 corrosion degree |
| Steel corrosion, DIN ISO 7120 / ASTM D665, method A, 24 h, 60°C | rust-free |
| Pour point, DIN ISO 3016, ASTM D97, ASTM D5950, ASTM D7346 | ≤ -40 °C |
| FAG FE8 rolling bearing test, DIN 51819-3, D-7.5 / 80-80, wear of cage | ≤ 200 mg |
| FAG FE8 rolling bearing test, DIN 51819-3, D-7.5 / 80-80, wear of rolling elements | ≤ 30 mg |
| FZG scuffing test, DIN ISO 14635-1, A / 8.3 / 90, failure load stage | ≥ 14 |
| Minimum shelf life from the date of manufacture – in a dry, frost-free place and in the unopened original container, approx. | 36 months |
Hazard Statements (CLP)
Signal word: Danger.
Hazard Statements (H-phrases)
- H411: Toxic to aquatic life with long-lasting effects.
Precautionary Statements (P-phrases)
Prevention:
- P273: Avoid release to the environment.
Response:
- P391: Collect spillage.
Hazardous materials. The forwarding charges may be raised, if shipping to: DE, AT, NL, GB, CH, CZ, IT, ES, FI, NO, BE, IE, RO, PL, FR, PT, LU, DK, LI, GR, SE, SK, BG, SI, CA, LT, EE, LV, HR, SA,
